8mm 10mm Thick Custom Cs Carbon Steel Plate Sheets Astm A36 6000 Mm X 2000 Mm
Product Details
| Material: | ASTM A36, Q235B | Finishing: | Hot Rolled Plate (HR), Cold Rolled Sheet (CR), 2B, 2D, BA NO(8), SATIN (Met With Plastic Coated) |
|---|---|---|---|
| Application: | Boiler&heat Exchanger, Energy, Petrochemical, Mining, Food, Paper, Gas And Fluid Industry | Shape: | Steel Plate Or Coil |
| Highlight |
plate astm a36,cold rolled plate |
||
Product Description
8mm 10mm Thickness Steel Plates Astm A36 Standards Size 6000 mm x 2000 mm
Detailed Product Description
| Width: | 100-2500mm | Grade: | Q235B A36 |
| Technique: | Hot Rolled | Type: | Steel Plate |
| Standard: | ASTM,AISI,JIS,DIN | Length: | 1000-12000mm |
| Thickness: | 1mm-120mm | Shape: | Flat Steel Plate |
8mm 10mm Thickness Steel Plates Astm A36 Standards Size 6000 mm x 2000 mm
ASTM A36 Carbon Steel Plates Specifications:
| Specifications | ASTM / ASME |
| Standard | EN 10025-2: 2004 Hot rolled products of structural steels. Technical delivery conditions for non-alloy structural steels |
| Specialize | Shim Sheet, Perforated Sheet, B. Q. Profile. |
| Size | 0.5 MM TO 200 MM THICK IN 1000 MM TO 2500 MM WIDTH & 2500 MM TO 12500 MM LENGTH |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
Equivalent Grade of ASTM A36 Carbon Steel Plates
| USA | Germany DIN,WNr |
Japan JIS |
France AFNOR |
England BS |
Canada HG |
European old EN |
Belgium NBN |
Spain UNE |
| 1015 A283C SSGr.33 |
RSt37-2 St37-2 |
SM400A SS400 |
E24-2 | 40A 40B |
230G | Fe360B Fe360BFN S235JRG2 |
AE235B | AE235B-FN |
| A283D A529 Gr.D |
RSt42-2 St 44-2 |
SS400 | E28-2 | 161-430 43A 43B |
260W 260WT |
Fe430B | AE295B | AE255B |
Chemical Properties of ASTM A36 Carbon Steel Plates
| C | Mn | P | S | Si | Co | CEV |
| max 0.27 | max 1.20 | max 0.04 | max 0.05 | 0.15 – 0.40 | max 0.20 | – |
Mechanical Properties of ASTM A36 Carbon Steel Plates
| Yield Point ksi, min | Tensile Strength ksi | % Elong. 2” Bend |
| 36 | 58-80 | 23 |
