Place of Origin: | JIANGSU, CHINA |
Brand Name: | HDT |
Certification: | ISO9001,ASME,PED |
Model Number: | A179, SAL179 |
Minimum Order Quantity: | 25T |
---|---|
Price: | 800 - 9000 USD / ton |
Packaging Details: | seaworthy packing for exporting |
Delivery Time: | 60-75days |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | About 10000 ton / month |
Product Name: | Seamless Carbon Steel Boiler Tube | Application: | For High, Middle, Low Pressure Boiler And Pressure Purpose |
---|---|---|---|
Standard: | A179,SA179 | Technique: | Seamless |
Section Shape: | Round | Material: | Carbon Steel |
Highlight: | SA179SMLS Boiler Pressure Tube,SA179SMLS Seamless Tube,Carbon Steel Sa 179 Seamless Tube |
A179/SA179SMLS Carbon Steel Tube For High, Middle , Low Pressure Boiler And Pressure Purpose
A179/SA179SMLS Carbon Steel Tube For High, Middle , Low Pressure Boiler And Pressure Purpose
Detail:
Standard: ASTM A179/SA179SMLS
Size:(mm)
Out Dimensions: 12.7mm – 114.3mm
Wall Thickness: 0.8mm - 15mm
Length: Fixed(6m,9m,12,24m) or normal length(5-12m)
Description:
ASTM ASTM A179, A179SMLS
Seamless Carbon Steel Boiler Tubes For High-Pressure Service.
Steel Grde:
Grade A
Packing:
Beveled/black painting/ plastic caps/ in bundles/ steel strips/ wooden protection
Inspection and Test:
Chemical Composition Inspection, Mechanical Properties Test(Tensile Strength, Yield Strength,Elongation, Flaring, Flattening, Bending, Hardness, Impact Test),Surface and Dimension Test,Nodestructive Test, Hydrostatic Test.
Surface treatment:
Oil-dip, Varnish, Passivation, Phosphating, Shot Blasting
Mark:
As requested.
Delivery Condition:
Annealed, Normalized, Normalized and Tempered
Chemical composition:
Product | Ttem | Grade | Chemical composition | |||||||
C | Si | Mn | P.≤ | S.≤ | Cr | Ni | others | |||
Carbon steel | 1 | 10 | 0.07/0.13 | 0.17/0.37 | 0.35/0.65 | 0.03 | 0.03 | ≤0.15 | ≤0.30 | Cu≤0.25 |
2 | 20 | 0.17/0.23 | 0.17/0.37 | 0.35/0.65 | 0.03 | 0.03 | ≤0.25 | ≤0.30 | Cu≤0.25 | |
3 | A179 | 0.06/0.18 | - | 0.27/0.63 | 0.03 | 0.03 | - | - | - | |
4 | A192 | 0.06/0.18 | ≤0.25 | 0.27/0.63 | 0.03 | 0.03 | - | - | - |
Mechanical properties:
Item | Mark | Tensile property | Hardness | ||||
Extension strength Rm Mpa | Lower Yield strength Rel or Rp0.2 MPa | lower Yield strength ReL or Rp0.2 Mpa | |||||
Thickness | Thickness | ||||||
≤16 | >16 | <5.1 | ≥5.1 | ||||
≥ | ≤ | ||||||
1 | 10 | 335~475 | 205 | 195 | 24 | - | - |
2 | 20 | 410~530 | 245 | 235 | 20 | - | - |
3 | A179 | ≥325 | 180 | 35 | - | - | |
4 | A192 | ≥325 | 180 | 35 | 77HRB | 137HB |
Applications:
1, For evaporator, heat exchangers, condensers, heat transfer equipment and similar pipes.
2, Widely used in the mechanical treatment field, petrochemical industry, transport and construction field
3, Ordinary structural purposes and mechanic structural purposes, for example in construction field, fulcrum bearing etc;
4, The transportation of fluids in the projects and big equipments, for example transport of water, oil, gas etc
5, Can be used in low and medium pressure boiler for the transportation of fluids, for example steam tube, big smoke tube, small smoke tube, generating tube etc
Inspection and Test:
Chemical Composition Inspection, Mechanical Properties Test(Tensile Strength,Yield Strength,
Elongation, Flaring, Flattening, Bending, Hardness, Impact Test), Surface and Dimension Test,No-destructive Test, Hydrostatic Test.
Contact Person: Mrs. Sandy
Tel: 008615151590099
Fax: 86-512-5877-4453
