Ss Stainless Steel Seamless Pipe / Cold Drawn Steel Pipe DIN17456 EN 10216 5 1.4301
Product Details
| Material: | DIN17456, DIN 17458 EN 10216-5 TC 1/2 1.4301, 1.4307, 1.4404, | Finishing: | Solution Annealed & Pickled |
|---|---|---|---|
| Application: | Boiler, Energy, Petrochemical, Mining, Food, Paper, Gas And Fluid Industry | Shape: | Round Seamless |
| OD: | 6.00mm To 830mm | WT: | 0.5mm To 48mm |
| Highlight |
ss seamless tube,seamless stainless steel tube |
||
Product Description
Stainless Steel Seamless Pipe:DIN17456, DIN 17458, EN 10216-5 1.4301, 1.4307, 1.4404, cold drawing & rolling
Hua Dong Energy Technology is the most leading manufacturer of steel tubes, pipes, plates for boilers, heat exchangers, condensers, economizer with more than 35 years of production experiences. The annual turnover is over 110 U.S.A. Dollars.
German-Standards
DIN 17456 Seamless circular austenitic stainless steel tubes for general service
DIN 17457 Welded circular austenitic stainless steel tubes subject to special requirements
DIN 17458 Seamless circular austenitic stainless steel tubes subject to special requirements
DIN 17459 Seamless circular high-temperature austenitic stainless steel tubes
DIN 28180-85 Seamless steel tubes for tubular heat exchangers
DIN EN ISO 1127 Seamless stainless steel tubes (Dimensions and weights)
EN10305-1 Steel Tubes for Precision Application-Seamless Cold Drawn Tubes
EN10305-2 Steel Tubes for Precision Application-Welded Cold Drawn Tubes
EN10305-3 Steel Tubes for Precision Application-Welded Cold Sized Tubes
EN10305-4 Steel Tubes for Precision Application-Seamless Cold Drawn Tubes for Hydraulic and Pneumatic Power Systems
EN10305-3 Steel Tubes for Precision Application-Welded and COld Sized Square and Rectangular Tubes
EN 10216-1/ DIN 17175 Seamless Steel Tubes for Pressure Purposes
EN 10216-2 Seamless Steel Tubes for Pressure Purposes-Non-alloy and alloy steel tubes with specified elevated temperature properties
EN 10216-4 Seamless Steel Tubes for Pressure Purposes
EN 10217-1 Welded Steel Tubes for Pressure Purposes-Non-Alloy Steel Tubes with specified room temperature properties-P195TR1, P235TR1,P265TR1, P195TR2, P235TR2, P265TR2
EN 10296-1 Welded Circular Steel Tubes for Mechanical and General Engineering Purpose-Non-Alloy and Alloy Steel Tubes.
| Grade | Material number |
C | Si | Mn | P | S | N | Cr | Mo | Ni | Ti | others |
| Ferritic or martensitic steels | ||||||||||||
| X2CrTi12 | 1.4512 | 0.030 |
1.00 | 1.00 | 0.040 | 0.015 | 10.50to12.50 | 6×(C+N)to0.65 | ||||
| X6CrAl13 | 1.4002 | 0.08 |
1.00 | 1.00 | 0.040 | 0.015 | 12.00to14.00 | 0.10to0.30Al | ||||
| X6Cr17 | 1.4016 | 0.08 |
1.00 | 1.00 | 0.040 | 0.015 | 16.00to18.00 | |||||
| X3CrTi17 | 1.4510 | 0.05 |
1.00 | 1.00 | 0.040 | 0.015 | 16.00to18.00 | 4×(C+N)+0.15 to 0.80 | ||||
| X12Cr13 | 1.4006 | 0.08 to 0.15 | 1.00 | 1.50 | 0.040 | 0.015 | 11.50to13.50 | 0.75 |
||||
| Austenitic steels | ||||||||||||
| X5CrNi18-10 | 1.4301 | 0.07 |
1.00 | 2.00 | 0.045 | 0.015 | 0.11 |
17.00to19.50 | 8.00to10.50 | |||
| X2CrNi19-11 | 1.4306 | 0.030 |
1.00 | 2.00 | 0.045 | 0.015 | 0.11 |
18.00to20.00 | 10.00to12.00 | |||
| X2CrNiN18-10 | 1.4311 | 0.030 |
1.00 | 2.00 | 0.045 | 0.015 | 0.12to0.22 | 17.00to19.50 | 8.50to11.50 | |||
| X6CrNiTi18-10 | 1.4541 | 0.08 |
1.00 | 2.00 | 0.045 | 0.015 | 17.00to19.00 | 9.00to12.00 | 5×C to 0.70 | |||
| X6CrNiNb18-10 | 1.4550 | 0.08 |
1.00 | 2.00 | 0.045 | 0.015 | 17.00to19.00 | 9.00to12.00 | 10×Cto1.00Nb | |||
| X5CrNiMo17-12-2 | 1.4401 | 0.07 |
1.00 | 2.00 | 0.045 | 0.015 | 0.11 |
16.50to18.50 | 2.00to2.50 | 10.00to13.00 | ||
| X2CrNiMo17-12-2 | 1.4404 | 0.030 |
1.00 | 2.00 | 0.045 | 0.015 | 0.11 |
16.50to18.50 | 2.00to2.50 | 10.00to13.00 | ||
| X6CrNiMoTi17-12-2 | 1.4571 | 0.08 |
1.00 | 2.00 | 0.045 | 0.015 | 16.50to18.50 | 2.00to2.50 | 10.50to13.50 | 5×C to 0.70 | ||
| X2CrNiMoN17-13-3 | 1.4429 | 0.030 |
1.00 | 2.00 | 0.045 | 0.015 | 0.12to0.22 | 16.50to18.50 | 2.50to3.00 | 11.00to14.00 | ||
| X2CrNiMo18-14-3 | 1.4435 | 0.030 |
1.00 | 2.00 | 0.045 | 0.015 | 0.11 |
17.00to19.00 | 2.50to3.00 | 12.50to15.00 | ||
| X3CrNiMo17-13-3 | 1.4436 | 0.05 |
1.00 | 2.00 | 0.045 | 0.015 | 0.11 |
16.50to18.50 | 2.50to3.00 | 10.50to13.00 | ||
| X2CrNiMoN17-13-5 | 1.4439 | 0.030 |
1.00 | 2.00 | 0.045 | 0.015 | 0.12to0.22 | 16.50to18.50 | 4.00to5.00 | 12.50to14.50 | ||
Grade 304 / 304L / 304H DIN17456 DIN 17458 EN 10216-5 TC 1/2 Stainless Steel Seamless Pipe
DIN17456 DIN 17458 EN 10216-5 TC 1/2 1.4301, 1.4307, 1.4404, Stainless Steel Seamless Pipe
Final Finishing:
Solution Annealed & Pickled
Size according to ANSI B16.10: B16.19 , SCH5S, SCH10S, SCH20, SCH30, SCH40S, SCH60, SCH80S, SCH100, SCH120, SCH160, XS, XXS.
Application:
- Food processing equipment, particularly in beer brewing, milk processing & wine making.
- Kitchen benches, sinks, troughs, equipment and appliances
- Architectural panelling, railings & trim
- Chemical containers, including for transport
- Heat Exchangers
- Woven or welded screens for mining, quarrying & water filtration
- Threaded fasteners
- Springs
- Ship building, onshore , offshore, Maire.
- Others
Product Highlights
