Zhangjiagang Hua Dong Energy Technology Co., Ltd.
Sales & Support:
 |
| Place of Origin: | China(Mainland) |
| Brand Name: | HDT |
| Certification: | ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008 |
| Model Number: | TP304,TP304L,TP304H,TP321,TP316L,S31803,SUS304,SUS304L,SUH304H,SUS321,SUS316L,SUS329J3L |
| Minimum Order Quantity: | 5T |
|---|---|
| Price: | 800 - 9000 USD / ton |
| Packaging Details: | seaworthy packing for exporting |
| Delivery Time: | 60-75days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | About 10000 ton / month |
| Material: | TP304,TP304L,TP304H,TP321,TP316L,S31803,SUS304,SUS304L,SUH304H,SUS321,SUS316L,SUS329J3L | Finishing: | Annealed & Pickled/Bright Annealed |
|---|---|---|---|
| Application: | Boiler, Energy, Petrochemical, Mining, Food, Paper, Gas And Fluid Industry | Shape: | Round Seamless |
| Outer Diameter: | 6.00mm To 830mm | Wall Thickness: | 0.5mm To 48mm |
| Highlight: | ss welded pipe,stainless steel erw pipe |
||
Stainless Steel Welded Pipes ASTM A312 TP304 TP304L TP304H TP321 TP316L ASTM A790 S31803, SCH10, SCH40,6M 11.8M
Hua Dong Energy Technology has more than 35 years experience for heat exchanger tube / boiler tube/ cooling tube,
Standard Specification:
ASTM A249 / A249M - 10a Standard Specification for Welded Austenitic Steel Boiler, Superheater,
Heat-Exchanger, and Condenser Tubes
ASTM A269 - 10:Standard Specification for Seamless and Welded Austenitic Stainless Steel Tubing
for General Service
ASTM A312 / A312M - 12:Standard Specification for Seamless, Welded, and Heavily Cold Worked
Austenitic Stainless Steel Pipes
ASTM A358/A358M-08a:Standard Specification for Electric-Fusion-Welded Austenitic
ASTM A778 - 01(2009)e1:Standard Specification for Welded, Unannealed Austenitic Stainless
Steel Tubular Products
ASTM A789 / A789M - 10a:Standard Specification for Seamless and Welded Ferritic Austenitic Stainless Steel Tubing for General Service
ASTM A790 / A790M - 11:Standard Specification for Seamless and Welded Ferritic Austenitic Stainless Steel Pipe
Others like BS, JIS , DIN , EN , GOST standard we all can supply .
Material Grade:
| American Standard | Austenitic Steel: TP304,TP304L,TP304H, TP304N, TP310S,TP316,TP316L,TP316Ti,TP316H, TP317,TP317L, TP321, TP321H,TP347, TP347H,904L… Duplex Steel : S32101,S32205,S31803,S32304,S32750, S32760 Others:TP405,TP409, TP410, TP430, TP439,... |
| Europen Standard | 1.4301,1.4307,1.4948,1.4541,1.4878,1.4550,1.4401,1.4404,1.4571,1.4438, 1.4841,1.4845,1.4539,1.4162, 1.4462, 1.4362, 1.4410, 1.4501 |
| Russia Standard | 08Х17Т,08Х13,12Х13,12Х17,15Х25Т,04Х18Н10,08Х20Н14С2, 08Х18Н12Б,10Х17Н13М2Т,10Х23Н18,08Х18Н10,08Х18Н10Т, 08Х18Н12Т,08Х17Н15М3Т,12Х18Н10Т,12Х18Н12Т,12Х18Н9, 17Х18Н9, 08Х22Н6Т, 06ХН28МДТ |
Designation: A312/A312M-04a / ASTM A790 / A790M - 11:
Standard specifications For Welded,And Heavily Cold Worked Austenitic
Stainless Steel Pipe
If client has inspection requirements, we can accept the following inspection:
| Manufacture Process | ERW Welded ( ELD ) Pipe |
Quality Inspection |
|
Mechanical Requirements |
Grade UNS Designation Tensile Strength Yield Strength Min Ks i [M pa] Min Ks i [M pa] TP304 S30400 75 [515] 30 [205] TP304L S30403 70 [485] 25 [170] TP309S S30908 75 [515] 30 [205] TP310S S31008 75 [515] 30 [205] TP316L S31603 70 [485] 25 [170] .... .... ..... .... |
|
|
|
Size Range:
| Production | Outside Diameter | Wall Thickness |
| Welded Pipe | 6.00mm to 830mm | 0.5mm to 48mm |
Final Finishing:
Solution Annealed & Pickled
Contact Person: Mrs. Sandy
Tel: 008615151590099
Fax: 86-512-5877-4453
