Name: Decorative Seamless Welded Stainless Steel Pipe For Baluster Handrail Satin Mirror
Brand: HDT
SKU: TP304,TP304L,TP304H, TP304N, TP310S,TP316,TP316L,TP316Ti,TP316H, TP317,TP317L, TP321, TP321H,TP347, TP347H
Price: 800 USD
Availability: InStock
Rating: 4.7 (173 reviews)

Home Products Seamless Welded Stainless Steel Pipe

Decorative Seamless Welded Stainless Steel Pipe For Baluster Handrail Satin Mirror

Product Details:

Place of Origin:	China(Mainland)
Brand Name:	HDT
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	TP304,TP304L,TP304H, TP304N, TP310S,TP316,TP316L,TP316Ti,TP316H, TP317,TP317L, TP321, TP321H,TP347, TP347H

Payment & Shipping Terms:

Minimum Order Quantity:	5T
Price:	800 - 9000 USD / ton
Packaging Details:	seaworthy packing for exporting
Delivery Time:	60-75days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	About 10000 ton / month

Contact Now

Detailed Product Description

Material:	TP304,TP304L,TP304H, TP304N, TP310S,TP316,TP316L,TP316Ti,TP316H, TP317,TP317L, TP321, TP321H,TP347, TP347H	Finishing:	Annealed & Pickled/Bright Annealed
Application:	Boiler, Energy, Petrochemical, Mining, Food, Paper, Gas And Fluid Industry	Shape:	Round Seamless
Outer Diameter:	6.00mm To 830mm	Wall Thickness:	0.5mm To 48mm
Highlight:	ss welded pipe , ss welded tube

Welded Stainless Steel Mechanical Pipe

Hua Dong Energy Technology has more than 35 years experience for heat exchanger tube / boiler tube/ cooling tube,

Standard Specification for Welded Austenitic Steel Boiler, Superheater, Heat-Exchanger, and Condenser Tubes

Overview
1.1 This specification covers welded stainless steel tubing for mechanical applications where appearance, mechanical properties, or corrosion resistance is needed.
1.2 This specification covers as-welded or cold-reduced mechanical tubing in sizes to 16 in. (406.4 mm) outside diameter, inclusive (for round tubing) and in wall thicknesses 0.020 in. (0.51 mm) and over.
1.3 Tubes shall be furnished in one of the following shapes as specified by the purchaser: round, square, rectangular, or special.
1.4 Supplementary requirements of an optional nature are provided and when desired shall be so stated in the order.
1.5 Values stated in inch-pound units, in accordance with the specifications, are to be regarded as the standard.

Tube Gauge for ASTM A554 Round

O.D./In.	Wall/In.	Wt./Ft.
.500	.049	.236
.625	.035	.221
.750	.065	.476
.875	.035	.314
1.000	.049	.498
1.000	.065	.649
1.000	.083	.813
1.250	.049	.629
1.250	.065	.823
1.500	.035	.548
1.500	.065	.996

O.D./In.	Wall/In.	Wt./Ft.
1.625	.065	1.083
1.750	.035	.641
1.750	.120	2.090
1.875	.049	.956
2.000	.035	.735
2.000	.049	1.021
2.000	.065	1.343
2.250	.049	1.152
2.500	.049	1.283
3.000	.065	2.030
4.000	.065	2.730

Tube Gauge for ASTM A554 Square

O.D./In.	Wall/In.	Wt./Ft.
.750 x .750	.065	.605
.750 x .750	.120	1.028
1.000 x 1.000	.049	.634
1.000 x 1.000	.065	.827
1.000 x 1.000	.083	1.035
1.000 x 1.000	.120	1.436
1.250 x 1.250	.065	1.047
1.250 x 1.250	.083	1.317
1.250 x 1.250	.120	1.844
1.500 x 1.500	.065	1.268
1.500 x 1.500	.083	1.599
1.500 x 1.500	.120	2.252
1.500 x 1.500	.180	3.230
1.750 x 1.750	.120	2.660
2.000 x 2.000	.065	1.710
2.000 x 2.000	.083	2.164
2.000 x 2.000	.120	3.050
2.000 x 2.000	.180	4.136
2.000 x 2.000	.250	5.410

O.D./In.	Wall/In.	Wt./Ft.
2.500 x 2.500	.083	2.730
2.500 x 2.500	.120	3.900
2.500 x 2.500	.180	5.352
3.000 x 3.000	.083	3.290
3.000 x 3.000	.109	4.250
3.000 x 3.000	.120	4.750
3.000 x 3.000	.180	6.578
3.000 x 3.000	.250	8.810
4.000 x 4.000	.120	6.460
4.000 x 4.000	.180	9.351
4.000 x 4.000	.250	12.210
5.000 x 5.000	.250	16.350
6.000 x 6.000	.250	19.020
6.000 x 6.000	.375	27.120
6.000 x 6.000	.500	38.123
8.000 x 8.000	.250	26.528
8.000 x 8.000	.375	39.291
8.000 x 8.000	.500	51.721

Tube Gauge for ASTM A554 Rectangular

O.D./In.	Wall/In.	Wt./Ft.
.750 x 1.500	.065	.937
1.000 x 1.500	.083	1.317
1.000 x 2.000	.065	1.270
1.000 x 2.000	.120	2.252
1.000 x 3.000	.065	1.710
1.500 x 2.500	.065	1.710
1.500 x 3.000	.120	3.480
2.000 x 3.000	.120	3.900
2.000 x 3.000	.180	5.352

O.D./In.	Wall/In.	Wt./Ft.
2.000 x 4.000	.120	4.750
2.000 x 4.000	.180	6.578
2.000 x 4.000	.250	8.810
2.000 x 5.000	.180	8.060
2.000 x 6.000	.180	9.420
2.000 x 6.000	.250	12.210
3.000 x 4.000	.120	5.610
4.000 x 6.000	.180	11.900
4.000 x 6.000	.250	15.620
4.000 x 6.000	.375	23.994
4.000 x 6.000	.500	31.324

Decorative Seamless Welded Stainless Steel Pipe For Baluster Handrail Satin Mirror 3
