ASTM A249 TP347 347H Boiler Stainless Steel Erw Pipe / Ss Erw Pipe 100% PMI Test

ASTM A249 TP347 347H Boiler Stainless Steel Erw Pipe / Ss Erw Pipe 100% PMI Test

  • ASTM A249 TP347 347H Boiler Stainless Steel Erw Pipe / Ss Erw Pipe 100% PMI Test
  • ASTM A249 TP347 347H Boiler Stainless Steel Erw Pipe / Ss Erw Pipe 100% PMI Test
  • ASTM A249 TP347 347H Boiler Stainless Steel Erw Pipe / Ss Erw Pipe 100% PMI Test
  • ASTM A249 TP347 347H Boiler Stainless Steel Erw Pipe / Ss Erw Pipe 100% PMI Test
ASTM A249 TP347 347H Boiler Stainless Steel Erw Pipe / Ss Erw Pipe 100% PMI Test
Product Details:
Place of Origin: China(Mainland)
Brand Name: HDT
Certification: ASME, TUV, SGS, ABS, PED, ISO9001, Grade A
Model Number: TP347 / 347H, 300 Series Stainless Steel
Payment & Shipping Terms:
Minimum Order Quantity: 5T
Price: 800 - 9000 USD / ton
Packaging Details: seaworthy packing for exporting
Delivery Time: 60-75days
Payment Terms: L/C, T/T, Western Union
Supply Ability: About 10000 ton / month
Contact Now
Detailed Product Description
Material: TP347 / 347H, 300 Series Stainless Steel Finishing: Solution Annealed & Pickled
Application: Boiler&heat Exchanger, Energy, Petrochemical, Mining, Food, Paper, Gas And Fluid Industry Shape: Welded Tube
OD: 5.80mm To 2032mm WT: 0.25mm To 28mm
Highlight:

stainless steel welded pipe

,

duplex stainless steel tube

ASTM A249 TP347 / 347H ERW Stainless Steel Welded Tube For Boiler , 100% PMI Test




Hua Dong Energy Technology deals with stainless steel welded pipe and tube already more than 10 years, every
year sell more than 5000 tons of stainless steel pipe and tube. Our client already cover more than 45
countries. Our stainless steel seamless pipe and tube was width used in Mining, Energy, Petrochemical,
Chemical Industry, Food plant, Paper plant, Gas and Fluid Industry etc.


ASTM A249 Standard :



Size OD Nominal Wall Outside Diameter Length Wall
1/2" (12.7) 0.065" (1.65)/0.049" (1.25) +/-0.005 (0.13) +1/8" (3.18) - 0 +/-10.0%
3/4" (19.1) 0.065" (1.65)/0.049" (1.25) +/-0.005 (0.13) +1/8" (3.18) - 0 +/-10.0%
1" (25.4) 0.065" (1.65)/0.049" (1.25) +/-0.005 (0.13) +1/8" (3.18) - 0 +/-10.0%
1-1/2" (38.1) 0.065" (1.65)/0.049" (1.25) +/-0.008" (0.20) +1/8" (3.18) - 0 +/-10.0%
2" (50.8) 0.065" (1.65)/0.049" (1.25) +/-0.008" (0.20) +1/8" (3.18) - 0 +/-10.0%
2-1/2" (63.5) 0.065" (1.65) +/-0.010" (0.25) +1/8" (3.18) - 0 +/-10.0%
3" (76.2) 0.065" (1.65) +/-0.010" (0.25) +1/8" (3.18) - 0 +/-10.0%
4" (101.6) 0.083" (2.11) +/-0.015" (0.38) +1/8" (3.18) - 0 +/-10.0%
6" (152.4) 0.083" (2.11) +/-0.030" (0.76) +1" (25.4) - 0 +/-10.0%
6" (152.4) 0.109" (2.77) +/-0.030" (0.76) +1" (25.4) - 0 +/-10.0%
8" (203.2) 0.109" (2.77) +0.061" (1.55)/-0.031" (0.79) +1" (25.4) - 0 +/-10.0%



Application :



a) For fluid and gas transport

b) Structure and machining

c) Heat exchanger pipes etc



Chemical Composition



  C(max) Si(max) Mn(max) P(max) S(max) Cr Ni Mo Ti
TP304/1.4301 0.080 1.00 2.00 0.045 0.030 18.0-20.0 8.0-10.5
TP304L/1.4307 0.035 1.00 2.00 0.045 0.030 18.0-20.0 8.0-12.0
TP304H/1.4948 0.04-0.10 1.00 2.00 0.045 0.030 18.0-20.0 8.0-12.0
TP316/1.4401 0.080 1.00 2.00 0.045 0.030 16.0-18.0 11.0-14.0 2.0-3.0
TP316L/1.4404 0.035 1.00 2.00 0.045 0.030 16.0-18.0 10.0-14.0 2.0-3.0
TP316Ti/1.4571 0.080 1.00 2.00 0.045 0.030 16.0-18.0 10.0-14.0 2.0-3.0 0.7>5x(C+N)
TP321/1.4541 0.080 1.00 2.00 0.045 0.030 17.0-19.0 9.0-12.0   0.7>5x(C+N)
TP317L/1.4449 0.080 1.00 2.00 0.045 0.030 18.0-20.0 11.0-14.0 3.0-4.0
TP347H/1.4912 0.04-0.10 1.00 2.00 0.045 0.030 17.0-19.0 9.0-13.0
TP309S/1.4833 0.080 1.00 2.00 0.045 0.030 22.0-24.0 12.0-15.0 0.75
TP310S/1.4845 0.080 1.00 2.00 0.045 0.030 24.0-26.0 19.0-22.0 0.75




ASTM A249 TP347 347H Boiler Stainless Steel Erw Pipe / Ss Erw Pipe 100% PMI Test 0
