Place of Origin: | China(Mainland) |
Brand Name: | HDT |
Certification: | ASME, TUV, SGS, ABS, PED, ISO9001, Grade A |
Model Number: | TP304 TP304L TP316 TP316L |
Minimum Order Quantity: | 5T |
---|---|
Price: | 800 - 9000 USD / ton |
Packaging Details: | seaworthy packing for exporting |
Delivery Time: | 60-75days |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | About 10000 ton / month |
Material: | TP304 TP304L TP316 TP316L | Finishing: | Solution Annealed & Pickled |
---|---|---|---|
Application: | Boiler&heat Exchanger, Energy, Petrochemical, Mining, Food, Paper, Gas And Fluid Industry | Shape: | Welded Tube |
OD: | 15.9mm To 406.4mm | WT: | 0.89mm To 5mm |
Highlight: | 316l stainless steel pipe,duplex stainless steel tube |
TP321 / 321H ERW Stainless Steel Welded Tube For Sewage Engineering
ASTM A249 Standard :
Size OD | Nominal Wall | Outside Diameter | Length | Wall |
1/2" (12.7) | 0.065" (1.65)/0.049" (1.25) | +/-0.005 (0.13) | +1/8" (3.18) - 0 | +/-10.0% |
3/4" (19.1) | 0.065" (1.65)/0.049" (1.25) | +/-0.005 (0.13) | +1/8" (3.18) - 0 | +/-10.0% |
1" (25.4) | 0.065" (1.65)/0.049" (1.25) | +/-0.005 (0.13) | +1/8" (3.18) - 0 | +/-10.0% |
1-1/2" (38.1) | 0.065" (1.65)/0.049" (1.25) | +/-0.008" (0.20) | +1/8" (3.18) - 0 | +/-10.0% |
2" (50.8) | 0.065" (1.65)/0.049" (1.25) | +/-0.008" (0.20) | +1/8" (3.18) - 0 | +/-10.0% |
2-1/2" (63.5) | 0.065" (1.65) | +/-0.010" (0.25) | +1/8" (3.18) - 0 | +/-10.0% |
3" (76.2) | 0.065" (1.65) | +/-0.010" (0.25) | +1/8" (3.18) - 0 | +/-10.0% |
4" (101.6) | 0.083" (2.11) | +/-0.015" (0.38) | +1/8" (3.18) - 0 | +/-10.0% |
6" (152.4) | 0.083" (2.11) | +/-0.030" (0.76) | +1" (25.4) - 0 | +/-10.0% |
6" (152.4) | 0.109" (2.77) | +/-0.030" (0.76) | +1" (25.4) - 0 | +/-10.0% |
8" (203.2) | 0.109" (2.77) | +0.061" (1.55)/-0.031" (0.79) | +1" (25.4) - 0 | +/-10.0% |
Material Grade :
American Standard | TP304 , TP304L , TP310S , TP316 , TP316L , TP316Ti , TP321 , TP347 , 904L , S31803 Etc |
European Standard | 1.4301 , 1.4306 , 1.4845 , 1.4401 , 1.4404 , 1.4571 , 1.4541 , 1.4550 , 1.4539 , 1.4462 Etc |
German Standard | X5CrNi18-10 , X2CrNi19-11 , X12CrNi25-21 , X5CrNi17-12-2 , X5CrNi17-12-3 , X2CrNiMo18-14-3 , X6CrNiTi18-10 , X6CrNiTb18-10 Etc |
1 . OD ( Outer Diameter ) : 15.9mm to 406.4mm
2 . WT ( Wall Thickness ) : 0.89mm to 5mm
3 . Length : According to customer's requirement
4 . Standards : ASTM A312; ASTM A269; ASTM A789; ASTM A790 ect
5 . Process Method : ERW, EFW etc
pplication : | a) For fluid and gas transport |
b) Structure and machining | |
c) Heat exchanger pipes etc | |
Advantages : | a) Superior surface finish |
b) Better mechanical property | |
c) More precise dimension | |
d) Perfect inspection method and inspection equipment | |
Price Item : | FOB, CFR, CIF or as negotiation |
Payment : | T/T, LC or as negotiation |
Contact Person: Mrs. Sandy
Tel: 008615151590099
Fax: 86-512-5877-4453
