Butt Stainless Elbow Fittings Seamless Welded Type Alloy 8367 UNS NO8367 6MO
Product Details
| Material: | Alloy 8020 , 8028, 8367 , 800, 800H, 800HT, 825, 925, 926 | Application: | Boiler, Energy, Petrochemical, Mining, Food, Paper, Gas And Fluid Industry |
|---|---|---|---|
| Size: | 1/8" TO 100 INCH | Radius: | 1D ,1.5D , 2.5D, 5D, 3D |
| Highlight |
butt weld elbow,carbon steel pipe elbow |
||
Product Description
Alloy Steel Butt Weld Fittings, A403 WP6XN (Alloy 8367 / UNS NO8367 / 6MO) , 90 Degree Elbow , LR , B16.9
Hua Dong Energy Technology from 1985 to now , already widly sells our Nickel alloy Butt Weld Fittings all over the world , which like : Saudi Arabia , Iran, Kuwait, Colombia , Singapore, Korea, Russia , Italy , Spain , UK , Gernmany , France,... And HDT brand has already won a good reputation in the market and project .
6% Molybdenum Superaustenitic Stainless Steel with Outstanding Resistance to Chloride Pitting, Crevice Corrosion and Stress-Corrosion Cracking. Alloy 6MO (UNS N08367) is comparable to and competes directly with AL6XN®.
The high nickel (24%) and molybdenum (6.5%) contents contribute to the alloys chloride stress-corrosion cracking resistance, while the molybdenum content also provides resistance to chloride pitting. The high levels of chromium (21%), molybdenum and nitrogen (0.22%) all serve to produce exceptional corrosion resistance.
Product range :
Size : 1/8"NB TO 100"NB
Schedule : SCH10, SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS, or special request from client .
Type : Seamless / Welded / Forged
Bending Degree : 30 Degree to 180 Degree in common , other bending Degree depend on client request .
Material Grade:
- ASTM A403 WP20CB (Alloy 8020 / UNS NO8020 / 2.4660)
- ASTM A403 WP6XN (Alloy 8367 / UNS NO8367 / 6MO )
- ASTM A403 WP700 (Alloy 8700 / UNS NO8700 )
- ASTM A403 WPNIC (Alloy 800 / UNS NO8800 / 1.4876)
- ASTM A403 WPNIC10 (Alloy 800H / UNS NO8810 / 1.4958)
- ASTM A403 WPNIC11 (Alloy 800HT /UNS NO8811 / 1.4958)
- ASTM A403 WP904L (904L / NO8904 / 1.4539)
- ASTM A403 WP1925 (925 / NO8925 )
- ASTM A403 WP1925N (926 / NO8926 / 1.4529)
Test Certificate:
Mill Test Certificate as per EN 10204 / 3.1B OR TPI 3.2 REPORT
| ANSI B.31.10 | Code for Pressure Piping | ANSI B.31.8 | Gas Transmission/Distribution Piping |
| ANSI B.31.3 | Petroleum Refinery Piping | ANSI B.36.10 | Standard for Wrought Steel Pipe |
| ANSI B.31.4 | Oil Transportation Piping | ANSI B.36.19 | Standard for Stainless Steel Pipe |
| ANSI B.31.5 | Refrigeration Piping Systems | ANSI B.16.10 | Valve Dimension Face & Ends |
| ANSI B.31.7 | Nuclear Power Piping | ANSI B.16.11 | Forged Fittings Socket Weld & Threaded |
Applications :
- Air Pollution Control
- Coal-fired power plant FGD systems
- Chemical Processing Equipment
- Food and Beverage Process Equipment Mining
- Coal mining wastewater brine treatment
- Gold mining pollution control units
- Offshore Oil and Gas Production- Seawater filtration, heat exchangers, piping systems
- Petroleum Refining Pharmaceuticals and Biotechnology Process equipment and piping systems
- Power Generation-Condensers, pumps, feed-water heaters, piping systems
- Pulp and Paper - Chlorine dioxide bleaching plants
- Seawater Treatment Desalination systems
Product Highlights
