Carbon Steel Pipe Elbow ASTM A234 WPB-S LR SR DN300 SCH120 BW SMLS B16.9 Black Surface
Product Details
| Material: | DN300/200 SCH120 B16.9 | Application: | Boiler, Energy, Petrochemical, Mining, Food, Paper, Gas And Fluid Industry |
|---|---|---|---|
| Size: | OD: 1/2" NB - 48" NB. WT: SCH 10S - SCH XXS | Standard: | ANSI B16.9, MSS SP 43 |
| Type: | Seamless / ERW / Welded / Fabricated /Forged | Form: | Elbows In Long & Short Radius In 45 Deg, 90 Deg, 180 Deg,Equal, Unequal Tee & Barred Tee |
| Highlight |
duplex steel elbow,butt weld elbow |
||
Product Description
Carbon Steel Fitting , ASTM A234 WPB-S ,90DEG ELBOW LR SR , DN300 SCH120 BW SMLS B16.9 , Black Surface
Carbon Steel Pipe Fitting - Long Radius Elbow 90
Standard
| Nominal Pipe Size |
Outside Diameter |
Inside Diameter |
Wall Thickness |
Center To End |
Pipe Schedule |
Weight Pounds |
| 1/2 | 0.84 | 0.622 | 0.109 | 1.5 | 40 | 0.16 |
| 3/4 | 1.05 | 0.824 | 0.113 | 1.5 | 40 | 0.17 |
| 1 | 1.32 | 1.049 | 0.133 | 1.5 | 40 | 0.4 |
| 1 1/4 | 1.66 | 1.38 | 0.14 | 1.88 | 40 | 0.55 |
| 1 1/2 | 1.9 | 1.61 | 0.145 | 2.25 | 40 | 0.8 |
| 2 | 2.38 | 2.07 | 0.154 | 3 | 40 | 1.6 |
| 2 1/2 | 2.88 | 2.47 | 0.203 | 3.75 | 40 | 3.2 |
| 3 | 3.5 | 3.07 | 0.216 | 4.5 | 40 | 4.8 |
| 3 1/2 | 4 | 3.55 | 0.226 | 5.25 | 40 | 6.6 |
| 4 | 4.5 | 4.03 | 0.237 | 6 | 40 | 8.9 |
| 5 | 5.56 | 5.05 | 0.258 | 7.5 | 40 | 15.1 |
| 6 | 6.62 | 6.07 | 0.28 | 9 | 40 | 24 |
| 8 | 8.62 | 7.98 | 0.322 | 12 | 40 | 47.8 |
| 10 | 10.75 | 10.02 | 0.365 | 15 | 40 | 83.4 |
| 12 | 12.75 | 12 | 0.375 | 18 | * | 123 |
| 14 | 14 | 13.25 | 0.375 | 21 | 30 | 155 |
| 16 | 16 | 15.25 | 0.375 | 24 | 30 | 206 |
| 18 | 18 | 17.25 | 0.375 | 27 | * | 262 |
| 20 | 20 | 19.25 | 0.375 | 30 | 20 | 324 |
| 24 | 24 | 23.25 | 0.375 | 36 | 20 | 466 |
| 30 | 30 | 29.25 | 0.375 | 45 | * | 720 |
| 36 | 36 | 35.25 | 0.375 | 54 | * | 1,039 |
| 42 | 42 | 41.25 | 0.375 | 63 | * | 1,420 |
| 48 | 48 | 47.25 | 0.375 | 72 | * | 2,000 |
Extra Strong
| Nominal Pipe Size |
Outside Diameter |
Inside Diameter |
Wall Thickness |
Center To End |
Pipe Schedule |
Weight Pounds |
| 1/2 | 0.84 | 0.546 | 0.147 | 1.5 | 80 | 0.26 |
| 3/4 | 1.05 | 0.742 | 0.154 | 1.5 | 80 | 0.29 |
| 1 | 1.32 | 0.957 | 0.179 | 1.5 | 80 | 0.48 |
| 1 1/4 | 1.66 | 1.27 | 0.191 | 1.88 | 80 | 0.79 |
| 1 1/2 | 1.9 | 1.5 | 0.2 | 2.25 | 80 | 1.2 |
| 2 | 2.37 | 1.93 | 0.218 | 3 | 80 | 2.1 |
| 2 1/2 | 2.88 | 2.32 | 0.276 | 3.75 | 80 | 3.8 |
| 3 | 3.5 | 2.9 | 0.3 | 4.5 | 80 | 6.3 |
| 3 1/2 | 4 | 3.36 | 0.318 | 5.25 | 80 | 8.6 |
| 4 | 4.5 | 3.82 | 0.337 | 6 | 80 | 12.5 |
| 5 | 5.56 | 4.81 | 0.375 | 7.5 | 80 | 21.2 |
| 6 | 6.63 | 5.76 | 0.432 | 9 | 80 | 34.4 |
| 8 | 8.63 | 7.63 | 0.5 | 12 | 80 | 71.3 |
| 10 | 10.75 | 9.75 | 0.5 | 15 | 60 | 111 |
| 12 | 12.75 | 11.75 | 0.5 | 18 | * | 158 |
| 14 | 14 | 13 | 0.5 | 21 | * | 201 |
| 16 | 16 | 15 | 0.5 | 24 | 40 | 270 |
| 18 | 18 | 17 | 0.5 | 27 | * | 348 |
| 20 | 20 | 19 | 0.5 | 30 | 30 | 422 |
| 24 | 24 | 23 | 0.5 | 36 | * | 604 |
| 30 | 30 | 29 | 0.5 | 45 | 20 | 997 |
| 36 | 36 | 35 | 0.5 | 54 | 20 | 1,380 |
| 42 | 42 | 41 | 0.5 | 63 | * | 1,880 |
| 48 | 48 | 47 | 0.5 | 72 | * | 2,502 |
Product range :
Size : 1/8"NB TO 48"NB IN
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Type : Seamless / ERW / Welded / Fabricated /Forged
Form : Eccentric Reducer, Concentric Reducer
Materials
Stainless Steel Reducer - SS Reducer
ASTM A403 WP Gr. 304, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L
Carbon Steel Reducer - CS Reducer
ASTM A 234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Low Temperature Carbon Steel Reducer - LTCS Reducer
ASTM A420 WPL3 / A420WPL6
Alloy Steel Reducer - AS Reducer
ASTM / ASME A/SA 234 Gr. WP 1, WP 5, WP 9, WP 11, WP 12, WP 22, WP 91
Duplex Steel Reducer
ASTM A 815 UNS NO S 31803 , S 32205.
Nickel Alloy Reducer
Standard
- ASTM / ASME SB 336.
- UNS 10276 (HASTELLOY C 276 Reducer)
- UNS 2200 (NICKEL 200 Reducer),
- UNS 2201 (NICKEL 201 Reducer),
- UNS 4400 (MONEL 400 Reducer),
- UNS 8020 (ALLOY 20 Reducer),
- UNS 8825 (INCONEL 825 Reducer),
- UNS 6600 (INCONEL 600 Reducer),
- UNS 6601 (INCONEL 601 Reducer),
- UNS 6625 (INCONEL 625 Reducer),
Value Added Services
- Hot Dip Galvanizing
- Epoxy Coating
Product Highlights
Carbon Steel Fitting , ASTM A234 WPB-S ,90DEG ELBOW LR SR , DN300 SCH120 BW SMLS B16.9 , Black Surface Carbon Steel Pipe Fitting - Long Radius Elbow 90 Standard Nominal Pipe Size Outside Diameter Inside Diameter Wall Thickness Center To End Pipe Schedule Weight Pounds 1/2 0.84 0.622 0.109 1.5 40 0...
