Titanium
Grade 1 - UNS R50250, Grade 2 - UNS R50400, Grade 5 - UNS R56400
Grade 7 - UNS R52400, Grade 9 - UNS R56320, Grade 12 - UNS R53400
Titanium Seamless Tubing
Titanium Seamless Pipe
Titanium Round Bar
Titanium Plate/Sheet
Titanium Seamless & Welded Butt-weld Fittings
Titanium Specialty Forgings
Alloys Now offers a large variety of products in materials of titanium including tubing, seamless- and welded pipe, butt weld fittings, flanges, round bar and plate titanium products:
Titanium
Commercially Pure & Alloyed
|
Tubing
Seamless |
1/16" - 1 1/2" OD |
0.016" - 0.125" WT |
| 3 mm - 40 mm OD |
0.5 mm - 3.0 mm WT |
Tubing
Welded |
1/2" - 4" OD |
0.028" - 0.250" WT |
| 12 mm - 100 mm OD |
1.0 mm - 6.0 mm WT |
Pipe
Seamless & Welded |
1/2" - 36" |
Sch 10S thru Sch 40S |
Butt Weld Fittings
Seamless & Welded |
1/2" - 36" |
Sch 10S thru Sch 40S |
Flanges
WN & Blind |
1/2" - 36" |
Sch 10S thru Sch 40S
150 lbs |
| Round Bar |
1/2" - 12" |
| Plate |
1/8" - 1" Thick |
Due to its unprecedented strength, lightness, stable and abundant market and non-corrosive characteristics, titanium has emerged as the metal of choice for aerospace, energy production and transportation, industry and medical, leisure and consumer products, notably golf clubs and bicycle frames. Furthermore, due to its strength and lightness, titanium is currently being tested in the automobile industry, which has found that the use of titanium for connecting rods and moving parts has resulted in significant fuel efficiency.
BENEFITS OF TITANIUM
- High strength,
- High resistance to pitting, crevice corrosion resistance.
- High resistance to stress corrosion cracking, corrosion fatigue and erosion,
- Cold bending for complex piping bends without fittings or flanges
- High strength to weight ratio,
- Weight saving possibilities
- Low modulus, high fracture toughness and fatigue resistance
- Suitability for coiling and laying on seabed
- Ability to withstand hot/dry and cold/wet acid gas loading
- Excellent resistance to corrosive and erosive action of high-temperature acid steam and brine
- Good workability and weldability
TITANIUM APPLICATIONS
- Aerospace
- Material of choice in desalination plants,
- Steam condensers
- Pulp and paper plants (chlorate bleaching facilities)
- Process equipment and piping
- Flue Gas Desulfurisation plants
- Disposals system for persistent or hazardous organic waste
- Seawater Management Systems,
- Process industries handling solutions containing chlorides,
- Flanges, fittings, valves, heat exchangers, risers and pipelines
- Sports, building material, medical industry and accessories.
| UNS R50250 Grade 1 |
| Carbon |
Iron |
Hydrogen |
Nitrogen |
Oxygen |
Titanium |
|
|
|
|
| 0.10 max |
0.20 max |
0.015 max |
0.03 max |
0.18 max |
remaining |
|
|
|
|
| UNS R50400 Grade 2 |
| Carbon |
Iron |
Hydrogen |
Nitrogen |
Oxygen |
Titanium |
|
|
|
|
| 0.10 max |
0.30 max |
0.015 max |
0.03 max |
0.25 max |
remaining |
|
|
|
|
| UNS R50550 Grade 3 |
| Carbon |
Iron |
Hydrogen |
Nitrogen |
Oxygen |
Titanium |
| 0.10 max |
0.30 max |
0.015 max |
0.05 max |
0.35 max |
remaining |
| Other each 0.1 max, total 0.4 max |
| UNS R50700 Grade 4 |
| Carbon |
Iron |
Hydrogen |
Nitrogen |
Oxygen |
Titanium |
| 0.10 max |
0.50 max |
0.015 max |
0.05 max |
0.40 max |
remaining |
| Other each 0.1 max, total 0.4 max |
| UNS R56400 Grade 5 |
| Aluminium |
Carbon |
Iron |
Hydrogen |
Nitrogen |
Oxygen |
Vanadium |
Titanium |
|
|
| 5.5 - 6.75 |
0.10 max |
0.40 max |
0.015 max |
0.05 max |
0.20 max |
3.5 - 4.5 |
remaining |
|
|
| UNS R52400 Grade 7 |
| Carbon |
Iron |
Hydrogen |
Nitrogen |
Oxygen |
Titanium |
| 0.10 max |
0.30 max |
0.015 max |
0.03 max |
0.25 max |
remaining |
| Other: Pd 0.12-0.25 |
| UNS R56320 Grade 9 |
| Aluminium |
Carbon |
Iron |
Hydrogen |
Nitrogen |
Oxygen |
Vanadium |
Titanium |
|
|
| 2.5 - 3.5 |
0.05 max |
0.25 max |
0.013 max |
0.02 max |
0.12 max |
2.0 - 3.0 |
remaining |
|
|
| UNS R52250 Grade 11 |
| Carbon |
Iron |
Hydrogen |
Nitrogen |
Oxygen |
Titanium |
| 0.10 max |
0.20 max |
0.015 max |
0.03 max |
0.18 max |
remaining |
| Other: Pd 0.12-0.25 |
| UNS R53400 Grade 12 |
| Carbon |
Iron |
Hydrogen |
Molybdenum |
Nitrogen |
Nickel |
Oxygen |
Titanium |
|
|
| 0.08 max |
0.30 max |
0.015 max |
0.2 - 0.4 |
0.03 max |
0.6 - 0.9 |
0.25 max |
remaining |
|
|
| UNS R52402 Grade 16 |
| Carbon |
Iron |
Hydrogen |
Nitrogen |
Oxygen |
Palladium |
| 0.10 max |
0.30 max |
0.010 max |
0.03 max |
0.25 max |
0.04 - 0.08 |
| Other: residuals each 0.1 max, total 0.4 max |
| Trade Name |
UNS |
Titanium Industry Specifications |
Chemical Composition |
Min.Tensile
(KSI) |
Min.Yield
(KSI) |
Hardness |
Modulus of Elasticity |
Poisson's Ratio |
| Grade 1 |
UNS R50250 |
AMS AMS-T-81915
ASTM F67(1), B265(1), B338(1), B348(1), B381(F-1), B861(1), B862(1), B863(1), F467(1), F468(1), F1341
MIL SPECMIL-T-81556 |
C 0.10 max
Fe 0.20 max
H 0.015 max
N 0.03 max
O 0.18 max
Ti Remaining |
35 |
25 |
14.9 |
103 GPa |
0.34-0.40 |
| Grade 2 |
UNS R50400 |
AMS 4902, 4941, 4942, AMS-T-9046
ASTM F67(2), B265(2), B337(2), B338(2), B348(2), B367(C-2), B381(F-2), B861(2), B862(2), B863(2), F467(2), F468(2), F1341
MIL SPECMIL-T-81556
SAE J467(A40) |
C 0.10 max
Fe 0.30 max
H 0.015 max
N 0.03 max
O 0.25 max
Ti Remaining |
50 |
40 |
14.9 |
103 GPa |
0.34-0.10 |
| Grade 5 |
UNS R56400 |
AMS 4905, 4911, 4920, 4928, 4930, 4931, 4932, 4934, 4935, 4954, 4963, 4965, 4967, 4993, AMS-T-9046, AMS-T-81915,AS7460, AS7461
ASTMB265(5), B348(5), B367(C-5), B381(F-5), B861(5), B862(5), B863(5), F1472
AWS A5.16 (ERTi-5)
MIL SPEC MIL-T-81556 |
AI 5.5-6.75 max
C 0.10 max
Fe 0.40 max
H 0.015 max
N 0.05 max
O 0.20 max
Ti Remaining
V 3.5-4.5 |
130 |
120 |
16.4 |
114 GPa |
0.30-0.33 |
| Grade 7 |
UNS R52400 |
ASTMB265(7), B338(7), B348(F-7), B861(7), B862(7), B863(7), F467(7), F468(7) |
C 0.10 max
Fe 0.30 max
H 0.015 max
N 0.03 max
O 0.25 max
Ti Remaining
Other Pd 0.12-0.25 |
50 |
40 |
14.9 |
103GPa |
- |
| Grade 9 |
UNS R56320 |
AMS 4943, 4944, 4945, AMS-T-9046
ASMESFA5.16(ERTi-9)
ASTMB265(9), B338(9), B348(9), B381(9), B861(9), B862(9), B863(9)
AWS A5.16(ERTi-9) |
AI 2.5-3.5
C 0.05 max
Fe 0.25 max
H 0.013 max
N 0.02 max
O 0.12 max
Ti Remaining
V 2.0-0-3.0 |
90 |
70 |
13.1 |
107GPa |
0.34 |
| Grade 12 |
UNS R53400 |
ASTMB265(12), B338(12), B348(12), B381(F-12), B861(12), B862(12), B863(12) |
C 0.08 max
Fe 0.30 max
H 0.015 max
Mo 0.2-0.4
N 0.03 max
Ni 0.6-0.9
O 0.25 max
Ti Remaining |
70 |
50 |
14.9 |
103GPa |
- |
Most of the titanium grades are of alloyed type with various additions of for example aluminum, vanadium, nickel, ruthenium, molybdenum, chromium or zirconium for the purpose of improving and/or combining various mechanical characteristics, heat resistance, conductivity, microstructure, creep, ductility, corrosion resistance, etc.
Titanium Benefits
High strength,
High resistance to pitting, crevice corrosion resistance,
High resistance to stress corrosion cracking, corrosion fatigue and erosion,
Cold bending for complex piping bends without fittings or flanges,
High strength to weight ratio.
Weight saving possibilities,
Low modulus, high fracture toughness and fatigue resistance,
Suitability for coiling and laying on seabed,
Ability to withstand hot/dry and cold/wet acid gas loading,
Excellent resistance to corrosive and erosive action of high-temperature acid steam and brine,
Good workability and weldability.
Titanium Chemical Composition
Palladium (Pd) and Ruthenium (Ru), Nickel (Ni) and Molybdenum (Mo) are elements which can be added to the pure titanium types in order to obtain a significant improvement of corrosion resistance particularly in slightly reducing environments where titanium otherwise might face some problems due to insufficient conditions for formation of the necessary protective oxide film on the metal surface. The formation of a stable and substantially inert protective oxide film on the surface is otherwise the secret behind the extraordinary corrosion resistance of titanium.
The mechanical properties of commercially pure titanium are in fact controlled by "alloying" to various levels of oxygen and nitrogen to obtain strength level varying between approximately 290 and 550 MPa. For higher strength levels alloying elements, e.g. Al and V have to be added. Ti 3AL 2.5V has a tensile strength of minimum 620 MPa in annealed condition and minimum 860 MPa in the as cold worked and stress relieved condition. The CP-titanium grades are nominally all alpha in structure, whereas many of the titanium alloys have a two phase alpha + beta structure. There are also titanium alloys with high alloying additions having an entire beta phase structure. While alpha alloys cannot be heat treated to increase strength, the addition of 2.5% copper would result in a material which responds to solution treatment and ageing in a similar way to aluminum-copper.
Titanium Density
Titanium is more then 46% lighter than steel. For comparative analysis, aluminum is approximately 0.12 lbs/cu.in, Steel is approximately 0.29 lbs/cu.in, and Titanium is approximately 0.16 lbs/cu.in.
Titanium Corrosion Resistance
Titanium's outstanding corrosion resistance is due to the formation of a tightly adherent oxide film on its surface. When damaged, this thin invisible layer immediately reforms, maintaining a surface which is completely resistant to corrosive attack in sea water and all natural environments. This oxide is so resistant to corrosion that titanium components often look brand new even after years of service.
|
