Hot Rolled Low Carbon Steel Plate Boiler A572 Grade 50 A572 Structural HSLA
Product Details
| Steel Grade: | A572 Grade 50 | Finishing: | Hot Rolled Steel Plate |
|---|---|---|---|
| Surface: | Black | Thickness: | 1-120mm |
| Width: | 100-3000mm | Form: | Coils, Foils, Rolls, Plain Sheet |
| Highlight |
mild steel plate,cold rolled plate |
||
Product Description
Boiler A572 Grade 50 Carbon Steel Plate A572 Structural Carbon&HSLA
We are the leading manufaturer of ASTM A572 Gr. 42, 50 CS Sheets Plates Coils, which have corrosion resistance comparable to austenitic varieties, but can be precipitation hardened to even higher strengths than the other martensitic grades. The low carbon content in ASTM A572 Gr. 42 Carbon Steel Plates minimizes carbide precipitation during welding to maintain corrosion resistance in as – welded structures. Ganpat Industrial Corporation is also one of the well – known supplier and trading house for high quality ASME SA 572 Gr. 50 Carbon Steel Coils, which are characterized by high chromium (19 % – 32 %) and molybdenum (up to 5 %) and lower nickel contents than austenitic stainless steels. At certain temperature range, ASTM A572 Gr. 42 Carbon Steel Slatting Coils exhibit brittleness. When nickel is added in ASME SA 572 Gr. 50 Carbon Steel Perforated Coils, for instance, the austenite structure of iron is stabilized. ASTM A572 Gr. 42 CS Plates have a mixed microstructure of austenite and ferrite, the aim usually being to produce a 50 / 50 mixes, although in commercial alloys the ratio may be 40 / 60. ASME SA 572 Gr. 50 CS Coils have roughly twice the strength compared to austenitic stainless steels. ASME SA 572 Gr. 50 CS Slatting Coils has also improved resistance to localized corrosion, particularly pitting, crevice corrosion and stress corrosion cracking.
ASTM A572 steel plate is used in a variety of structural applications including bridges, buildings, construction equipment, freight cars, machinery, truck parts and transmission towers.
A572 steel plate is produced in five grades: 42, 50, 55, 60 and 65. Leeco Steel stocks all five grades at its distribution centers.
A572 Availability |
||||
|---|---|---|---|---|
| THICKNESS | WIDTH | LENGTH | ||
| Grade 42 | 4" – 6" | 48" – 120" | 96" – 480" | Quote |
| Grade 50 | 3/16" – 4" | 48" – 120" | 96" – 480" | Quote |
| Grade 55 | 3/16" – 1 1/2" | 48" – 120" | 96" – 480" | Quote |
| Grade 60 | 3/16" – 1 1/4" | 48" – 120" | 96" – 480" | Quote |
| Grade 65 | 3/16" – 1 1/4" | 48" – 120" | 96" – 650" | Quote |
Make sure you see the rest of Leeco Steel's High Strength Low Alloy steel plate inventory.
ASTM A572 Chemical Composition
| A572 Steel Composition | ||||
|---|---|---|---|---|
| Grade 42 | Grade 50 | Grade 60 | Grade 65 | |
| Carbon | 0.21% | 0.23% | 0.26% | 0.23-0.26% |
| Manganese | 1.35% | 1.35% | 1.35% | 1.35-1.65% |
| Phosphorus | 0.03% | 0.03% | 0.03% | 0.03% |
| Sulfur | 0.03% | 0.03% | 0.03% | 0.03% |
| Silicon | 0.15-0.4% | 0.15-0.4% | 0.4% | 0.4% |
ASTM A572 Yield, Tensile & Elongation
The maximum stress points of A572 steel differ by grade.
| A572 Steel Strength | |||
|---|---|---|---|
| Grade | Yield Point (ksi) | Tensile Strength (ksi) | Min. 8" Elongation % |
| 42 | 42 | 60 | 20 |
| 50 | 50 | 65 | 18 |
| 60 | 60 | 75 | 16 |
| 65 | 65 | 80 | 15 |
Product Highlights
Boiler A572 Grade 50 Carbon Steel Plate A572 Structural Carbon&HSLA We are the leading manufaturer of ASTM A572 Gr. 42, 50 CS Sheets Plates Coils, which have corrosion resistance comparable to austenitic varieties, but can be precipitation hardened to even higher strengths than the other martensitic ...
High Frequency Welding Customized Coal Fired Steam Boiler Parts Stack Economizer Coil
High Frequency Welding Customized Coal Fired Steam Boiler Parts Stack Economizer Coil Boiler economizer Boiler Economizer is the energy improving device that helps to reduce the cost of operation by saving the fuel. The economizer in Boiler tends to make the system more energy efficient. In boilers, economizers are generally designed to exchange heat with the fluid, generally water. The exhaust from the boilers is generally in the temperature range of 200°C – 250°C, so there
High Frequency Welding Boiler Spiral Fin Tube For Economizer Heat Transfer
High Frequency Welding Boiler Spiral Fin Tube For Economizer Heat Transfer Boiler economizer Boiler Economizer is the energy improving device that helps to reduce the cost of operation by saving the fuel. The economizer in Boiler tends to make the system more energy efficient. In boilers, economizers are generally designed to exchange heat with the fluid, generally water. The exhaust from the boilers is generally in the temperature range of 200°C – 250°C, so there are a huge
Heat Exchanger H Type Boiler Parts Tube For Utility Power Station Plant
High Efficient Heat Exchang H Type High Temperature Resistance Boiler Parts For Utility/Power Station Plant Product Introduce H-fin Tubes have two steel discs,with fluorescent tubes symmetrically welded together to form fins(fins of butterfly piece)creating a shape that looks somewhat like the letter"H",creating an efficient energy saving, extension heating surface.H-fin Tubes also have a high rate of fusion welds and weld tensile strength.H-fin Tube is assembled with the H
Extension Heating Surface Boiler Fin Tube For Industrial Power Plant Boiler
Energy Saving Extension Heating Surface Boiler Fin Tube For Industrial Power Plant Boiler Product Description H-fin Tubes have two steel discs,with fluorescent tubes symmetrically welded together to form fins(fins of butterfly piece)creating a shape that looks somewhat like the letter"H",creating an efficient energy saving, extension heating surface. H-fin Tubes also have a high rate of fusion welds and weld tensile strength.H-fin Tube is assembled with the H economizer,
