Cold Rolled Steel Strip Black Annealing Coil DC01 SPCC Thickness 0.5 - 3.0mm 1250mm Width
Product Details
| Surface: | Cold Rolled Carbon Steel Plate | Material: | DC01, SPCC |
|---|---|---|---|
| Thickness: | 0.5mm-6mm | Width: | 50mm-1500mm |
| Coil Weight: | 3MT-9MT | Length: | 100mm To 12000mm |
| Highlight |
mild steel plate,cold rolled plate |
||
Product Description
Cold Rolled Steel Strip Black Annealing Coil DC01 SPCC Thickness 0.5-3.0mm 1250mm Width
Deep Drawing quality
1 Thickness: 0.5-6.0mm
2 Width: 100-1500mm
3 Inner diameter: 508mm
4 Steel Grade: SPCD, SPCE, DC03
5 Packing: standard export packing
6 Cutting and slitting can be requested as customer's designation.
COLD ROLLED STEEL COILS(CRC)
Width (mill edge): 914-1500mm
Max. Thickness: 0.3--2.0mm
Min. Thickness: 0.3mm
Inside diameter: 508mm or 610mm
Outside diameter: 850~1500mm
Description of goods: we can supply soft, semi-soft, cold hard and stainless worked cold-rolled steel coils at customer's option
Steel Grade: SPCC-SD, SPCC-1B, DC01, DC02, DC03, DC04
| Name | Cold rolled steel coil/sheet |
| Standard | JIS 3302 / ASTM A653 / EN10143 |
| Grade | Q235, SGCC, CGCC, SPCC, DX51D, DX52D, SPHC, DC01, DC03, DC04, ST12 |
| Width | 750~1250mm |
| Thickness | 0.12~3.0mm |
| Surface treatment | chromated / galvanized/oiled/annealed |
| ID coil | 508mm or 610mm |
| Coil weight | 3-8 MT |
| Package: | Standard exporting package |
| Application | Industrial panels, roofing and siding for painting |
| Price terms | FOB,CFR,CIF |
| Payment terms | 30%TT in advance+70% TT or irrevocable 100%L/C at sight |
| delivery time | within 60 days |
