ASTM A213 ASME SA213 T91 Alloy Steel Seamless Pipe Petroleum Chemical Industry
Product Details
| Product Name: | ASTM A213 ASME SA213 T91 | Application: | Boiler Pipe |
|---|---|---|---|
| Standard: | ASTM, BS, DIN, GB, ASME, ANSI, ASTM | Technique: | Cold Drawn, Seamless |
| Highlight |
seamless alloy steel pipe,hot rolled steel tube |
||
Product Description
ASTM A213 ASME SA213 T91 Seamless Alloy Steel Pipe for Boiler of Power Station
| Standard & Material: |
GB5310-2013 Standard: 20G,25MnG, 15MoG,15CrMoG, 20MoG, 12CrMoG, 12Cr2MoG, 12Cr1MoVG, 12Cr2MoWVTiB, 10Cr9Mo1VNb, 15CrMoG, 10CrMo910, ASTM A209M/AS-209M Standard A209T1/SA209 T1, A209 T1b/SA-209 T1b, A209T1a/SA209 T1a ASTM A210M/SA-210M Standard A210 A1/ SA-210 A1, A210C, SA-210C ASTM A213M/ASME SA 213 M Standard: T2, T5, T9, T11, T12, T22, T23, T24, T91, T911, T92, T122 ASTM A333M/ASME SA-333/SA333M Standard: Gr1, Gr3, Gr4, Gr6, Gr7,Gr8, Gr9, Gr10, Gr11 ASTM A335/ASME SA335 Standard: P1, P2, P5,P5b, P5c, P9, P11, P12,P21,P22,P23, P24, P91, P92 ASTM A519 Standard: 4118, 4130,4135,4137,4140 ASTM A691 Standard GRADE 91, CM65, CM70, CM75, CMSH70, CMS75, CMSH80, ASTM A691 Standard GRADE 1/2 Cr, GRADE 1CR, GRADE 1 1/4 CR, 2 1/4 Cr, 3CR, 5CR, 9 CR DIN17175 Standard: ST35.8, ST45.8, 15Mo3, 13CrMo44, 10CrMo910, 14MoV63,12Cr1MoV EN10216-2 Standard: P195GH, P235GH, P265GH, 13CrMo4-5, 10CrMo9-10, 16Mo3, 10CrMo5-5, X10CrMoVNb9-1 JIS G3458 Standard: STPA12, STPA20, STPA22, STPA23, STPA24, STPA25, STPA26 JIS G3441 Standard:SCR420 TK,SCM415 TK, SCM418 TK, SCM420TK, SCM430TK, SCM435TK, SCM440TK. NF A49-213/215 Standard: TU15D3, TU13CD4-04, TU10CD910, TUZ10CD505 Alloy C276 BS3059 Standard: S1-622-440, S2-622-440, S1-622-490, S2-622-490, S1-629-470, S2-629-470, S2-629-590 BS3604Standard: HFS625 CFS625 BS3606Standard: CFS625 |
| Size: | O.D:6-760mm W.T:1-80mm Fixed Length: 5.8m, 6m, 11.8m, 12m, or random length as required. |
| Application: |
1) Boiler, Superheater, Heat Exchanger; 2) Petroleum; 3) Aerospace; 4) Chemical; 5) Electric Power; 6) Military. Alloy steel pipe applies to petroleum, chemical industry, electric power, boiler, high temperature resistant, low temperature resistant, corrosion resistant part. |
| Testing | Tensile Test, Hardness Test, Impact Test, Bend Test, Flattening Test, Flaring Test, Hydrostatic or Nondestructive Test |
| Technique | Hot Rolled, Cold Drawn, Cold Rolled |
| Package | Export standard package; bundled wooden box, suit for all kinds of transport, or be required |
ASTM A213 T91 alloy pipes Chemical Composition
| Material | C | Si | Mn | P | S | Cr | Mo |
| A213 T91 | 0.15Max | 0.5Max | 0.30-0.60 | 0.025max | 0.025max | 4.00-6.00 | 0.45-0.65 |
ASTM A213 T91 alloy pipes Mechanical Property
| Material | Tensile Strength,Mpa | Yield Strength,Mpa | Elongation/% |
| A213 T91 | Min 415 | Min 205 | Max 20 |
seamless alloy tubes T91 are used for power stations, nuclear power plants, chemical plants,oil refineries,industrial plants and so on.
