Boiler Spiral Finned Tubes / Carbon Steel Heat Exchanger Economiser Tubes

Boiler Spiral Finned Tubes / Carbon Steel Heat Exchanger Economiser Tubes

  • Boiler Spiral Finned Tubes /  Carbon Steel Heat Exchanger Economiser Tubes
  • Boiler Spiral Finned Tubes /  Carbon Steel Heat Exchanger Economiser Tubes
  • Boiler Spiral Finned Tubes /  Carbon Steel Heat Exchanger Economiser Tubes
  • Boiler Spiral Finned Tubes /  Carbon Steel Heat Exchanger Economiser Tubes
Boiler Spiral Finned Tubes /  Carbon Steel Heat Exchanger Economiser Tubes
Product Details:
Place of Origin: CHINA
Brand Name: HDT
Certification: ISO9001,ASME,Grade A,SGS,EN,TUV
Model Number: Boiler Fin Tube
Payment & Shipping Terms:
Minimum Order Quantity: 5T
Price: 800 - 9000 USD / ton
Packaging Details: seaworthy packing for exporting
Delivery Time: 60-75days
Payment Terms: L/C, T/T, Western Union
Supply Ability: About 10000 ton / month
Contact Now
Detailed Product Description
Type: Fin Tube,Heat Exchanger Tube Application: Heater Parts,Heat Exchanger
Fin Material: Carbon Steel,stainless Steel,304L/316LStainless Steel Packing: Seaworthy Packing Of Fin Tube
Color: Customized Package: Wooden Case With Steel Frame,In Bundles,etc.
Highlight:

longitudinal finned tubes

,

square fin tube







                       Latest Technology Boiler Spiral Finned Tubes Economizer with Carbon Steel





Product Introduction


BaseTube material:

Stainless steel(SA213 304)

Dimension:

OD:16-140mm WT:2-10mm Length:1-25m



Fin material:

SA213-TP304H,Copper and so on



Fin type:

KL,L,LL,H ,spiral slot,low,Stud pipes-Visual, type

seamless copper stainless steel fin tube



Dimension:

Thickness of fin :0.5-4.0mm Height of fin:5-30mm Fin pitch :3.5-40mm



Make the craft:

steel tube polishing-tooth punching on steel strip-Solid rolling on steel trip-High frequency welding-Hydrostatic pressure test, chamfering, polishing-Quality inspection -Packaging

Produce method:extruded & serrated



Application:



air cooler, fired heater, heat exchanger, marine boiler, economizer, power plant boiler, HRSG boiler, waste heat recovery unit, air heater etc



Characteristic:1.Anti-corrosion2.Anti-wear3.Lower contact resistance 4.Higher Stability


Our products can be modified according to our customers' needs and the situation.we design and manufacture safe,reliable and efficient H-fin tubes.it  has also completed stand-alone product quality assurance systems.Production of H-fin tubes are with high heat transfer efficiency, they have flue gas resistance and are designed for a small space.

Technical parameters The high degree of fin 0-16mm(or outside diameter of fin φ25-φ75);
Pitch of fins 2.0-5.0mm; Length of finning tube 0.5~ 14m.
Single metal rolling finning tube Pure aluminum 1060 or aluminum alloy 6063,6061.
Outside diameter Shall be less than 40mm
Double metal rolling finning tube Tube-based protection from the outer layer of aluminum
tubes,corrosion-resistant,Tube-based can be made of carbon steel pipe,in addition to,stainless
steel tube and copper tube can also be used, as well as titanium alloy tube
Package The aluminum finned tubes are well packed in plastic film in the inner and steel fram
in the outer





Boiler Spiral Finned Tubes /  Carbon Steel Heat Exchanger Economiser Tubes 0



Specifications


1). Add the heat exchange area and reduce the number of tubes, also increase the fume flow section area to reduce the fume speed and abrasion.
2). H type fin tube can be made to double H type fin tube, high rigidness to fit long tube row.
3). H type fin economizer arranged in line to make the space into many small zones, averaged air flow to reduce the abrasion.
4). With straight channel to gain the best ash-blowing effect.
5). The compact structure to reduce the weight and reduce the manufacturing cost.

Base Tube Material Stainless Steel, Carbon Steel, Alloy Steel, Copper Alloy,Aluminum ,SA179
Fin Material Aluminum, Copper Alloy, Stainless Steel, Carbon Steel
Standard ASME SA213/ASTM; ASME EA 106, ASME SA178, ASTM B1111
Fin depth 0.5-3mm
Base pipe O.D 12.7-18mm
Fins per inch 8-20Nos (as customer's request)
Test Requirement Physical Property Test, Chemical Composition Analysis, Non-Destructive Test, Other Inspection and Test as customer's requirement.
Application Air Cooler, Charge Air Chiller, Condenser, Evaporator, Fluid Cooler, Gas Cooler, Oil Cooler, Radiator, Refrigeration, Steam to Air Heat Exchange, super heater etc.



Company Profile


Zhangjiagang Hua Dong Energy Technology Co., Ltd. is a high-tech enterprise specialized in producing all kinds of stainless, carbon and alloy steel tubes and pipes, steel plates which are widely used in the field of boiler&heat exchanger, energy, petrochemical, mining, food, paper, gas and fluid industry. And we have passed the attestations including ASME, TUV, Grade A, ISO9001, EN12952, EN10216, SO3834.



The company is the subsidiary of Zhangjiagang Hua Dong Boiler Co., Ltd, which is the most leading boiler and boiler parts manufacturer in China with a history of 35 years and annual turnover of 110 million U.S.A. dollars. Our products have been exported to over 30 countries like United States, Australia, Vietnam, Pakistan, Albania, Cambodia, India, Indonesia, South Korea, the Philippines, Turkey, Saudi Arab, Germany, Russia, Chile, Syria, Thailand, Bangladesh, France, Algeria, Mongolia and Singapore, Cuba, Iraq, Italy, Spain, Japan, Yugoslavia, Sri Lanka, the Czech republic, kyrgyzstan, Canada, Malaysia, the United Kingdom and so on.



Location:

Our company locates in Zhangjiagang city which is a port city, and is only 120km far away from Shanghai, 60km far away from Suzhou and 60km far away from Wuxi. The traffic is very convenient.
