168mm Boiler ASTM A210 Carbon Steel Seamless Tube For Power Station

Product Details:

Place of Origin:	China
Brand Name:	HDT

Payment & Shipping Terms:

Minimum Order Quantity:	5T
Price:	800 - 9000 USD / ton
Packaging Details:	seaworthy packing for exporting
Delivery Time:	Within 75days after getting the down payment
Payment Terms:	L/C, T/T, Western Union, , MoneyGram
Supply Ability:	About 10000 ton / month

Contact Now

Detailed Product Description

Product Name:	Seamless Tube For Boiler	Application:	Boiler Tube And Structure Pipe
Outer Diameter:	10 - 168mm	Standard:	AISI, ASTM, DIN, EN, GB, JIS
Certificates:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008	Brand:	HDT
Highlight:	ASTM A210 seamless boiler tubes , 168mm Carbon Steel Seamless Tube , A210 Carbon Steel Seamless Tube

Product Description

Boiler Tube ASTM A210 Carbon Steel Seamless Tube For Power Station

Quick Detail:
Standard: ASTM A210/A210M (ASME SA210/SA210M)
Seamless Medium-Carbon Steel Boiler and Superheater Tubes
Size:(mm)
Out Dimensions: 12.7mm-114.3mm
Wall Thickness: 0.8mm-15mm
Length: 5-25mm

Applications:

It is used for boiler and boiler flue tubes. Including safe end, vault and supporting tube and super heater min wall thickness seamless medium--carbon steel tube

Chemical Requirements:

STANDARD	GRADE	CHEMICAL COMPOSITION
STANDARD	GRADE	C	Si	Mn	P	S	Cr	Mo	Cu	Ni	V
ASTM A210	A-1	≤0.27	≥0.10	≤0.93	≤0.035	≤0.035
ASTM A210	C	≤0.35	≥0.10	0.291.06	≤0.035	≤0.035

Mechanical Properties:

Grade	Yield Strength (Mpa)	Tensile Strength (Mpa)	Elongation (%)
A-1	≥255	≥415	30
C	≥275	≥485	30

Wall Thickness Tolerance

ASME SA-210	OD	WT	WT Tolerance
	<=38.1	/	+20%,-0%
	>38.1	/	+20%,-0%

Description:

ASTM A210 is the standard covers seamless medium-carbon steel boiler and superheater tubes.ASTM A210 also covers minimum-wall-thickness, tubing sizes, boiler flues including safe ends, arch and stay tubes. ASTM A210 provides tensile and hardness properties but only applicable to certain size limitations. Material manufacturing shall be killed. Tubes shall be made by seamless process, marked as either hot-finished or cold-finished. Surface condition shall be specifically stated in the order. Chemical composition shall conform to the requirements. Elemental composition other than listed here shall not be permitted. Tension test, flattening test, flaring test, hardness test, hydrostatic or nondestructive electric test shall be made on specimens. Superheater tubes shall be formed without defects and shall withstand expansion, beading, forging, welding, and bending.

ASTM A210/A210M Seamless Medium-Carbon Steel Boiler Tubes
Seamless Medium-Carbon Steel Boiler and Superheater Tubes

Steel Grde:
Grade A1; Grade C
Packing:
Beveled/black painting/ plastic caps/ in bundles/ steel strips/ wooden protection
Inspection and Test:
Chemical Composition Inspection, Mechanical Properties Test(Tensile Strength, Yield Strength,Elongation, Flaring, Flattening, Bending, Hardness, Impact Test),Surface and Dimension Test,Nodestructive Test, Hydrostatic Test.
Surface treatment:
Oil-dip, Varnish, Passivation, Phosphating, Shot Blasting
Mark:
As requested.

Delivery Condition:
Annealed, Normalized, Normalized and Tempered
