TUV GB5310 Galvanised Carbon Steel Seamless Tube
Product Details
| Product Name: | Boiler Tube | Standard: | Chinese GB5310 |
|---|---|---|---|
| Application: | Heating-pipelines,containers,coal-saving Devices Superheaters And Reheaters | Main Steel Pipe Grade: | 20G 、 25MnG 、 15MoG 、 15CrMoG 、 12Cr2MoG 、 12Cr1MoVG |
| Material: | Carbon Steel | Port: | Shanghai |
| Highlight |
galvanised carbon steel seamless tube,GB5310 carbon steel seamless tube,TUV carbon steel seamless tube |
||
Product Description
Corrosion Resistant Galvanized Carbon Steel Seamless Pipe And Tube
Product Details
Chemical Compositon & Mechanical Propertise :
| Standard | Grade | Chemical Composition(%) | ||||||
| C | Mn | Si | V | Cr | Mo | P.S | ||
| GB5310 | 20G | 0.17~0.24 | 035~0.65 | 0.17~0.37 | / | / | / | ≤ 0.030 |
| 25MnG | 0.22~0.30 | 0.70~1.00 | 0.17~0.37 | / | / | / | ≤ 0.030 | |
| 15MoG | 0.12~0.20 | 0.40~0.80 | 0.17~0.37 | / | / | 0.25~0.35 | ≤ 0.030 | |
| 15CrMoG | 0.12~0.18 | 0.40~0.70 | 0.17~0.37 | / | 0.80~1.10 | 0.40~0.55 | ≤ 0.030 | |
| 12Cr2MoG | 0.08~0.15 | 0.40~0.70 | ≤ 0.50 | / | 2.00~2.50 | 0.90~1.20 | ≤ 0.030 | |
| 12Cr1MoVG | 0.08~0.15 | 0.40~0.70 | 0.17~0.37 | 0.15~0.30 | 0.90~1.20 | 0.25~0.35 | ≤ 0.030 | |
| Mechanical Propertise | Tensile Strength(Mpa) | Yield Strength(Mpa) | Elongation(%) | |||||
| 20G | 410~550 | ≥ 245 | ≥ 24 | |||||
| 25MnG | ≥ 415 | ≥ 240 | ≥ 22 | |||||
| 15MoG | 450~600 | ≥ 270 | ≥ 22 | |||||
| 15CrMoG | 440~640 | ≥ 235 | ≥ 21 | |||||
| 12Cr2MoG | 450~600 | ≥ 280 | ≥ 20 | |||||
| 12Cr1MoVG | 470~640 | ≥ 255 | ≥ 21 | |||||
Product Highlights
Corrosion Resistant Galvanized Carbon Steel Seamless Pipe And Tube Product Details Commodity hot dipped and pre-galvanized steel pipe OD 10-600mm(round) thickness 1.2-30mm length 3-12m or as per customers' requirements material Q195—Grade B, SS330, SPC, S185 Q215—Grade C,CS Type B, SS330, SPHC Q235-...
