ASTM A53 A192 Mild ERW Carbon Steel Boiler Tubes
Product Details
| Material: | Astm A335 P5 P9 Alloy Carbon Steel Welded Pipes | Finishing: | Annealed, Normalized, Normalized And Tempered |
|---|---|---|---|
| Application: | Boiler&heat Exchanger, Energy, Petrochemical, Mining, Food, Paper, Gas And Fluid Industry | Certificates: | ASME, TUV, SGS, CE, ISO9001, |
| Shape: | Welded Pipe | Technique: | Hot Rolled,ERW,Cold Drawn |
| Highlight |
A53 carbon steel boiler tubes,A192 carbon steel boiler tubes,ERW carbon steel boiler tubes |
||
Product Description
ASTM A53 A192 Boiler Tubes Cs Carbon Steel Welded Tube / Pipe Mild Carbon
Detailed Product Description
| STANDARD | ASTM,DIN,JIS,GB,SUS,TP | MATERIAL | Provide according to customer needs and uses |
| TECHNIQUE | Hot rolled/Cold rolled | PACKAGING | Export packing standard |
| PAYMENT | TT(T/T) | REMARK | Accept customized products |
| Ends | 1) Plain 2) Beveled 3) Thread with Coupling or cap 4)Bending |
Surface Treatment | 1) Bared 2) Black Painted or other colors painted(varnish coating) 3) Galvanized 4) With Oiled 5) 3 PE, FBE, corrosion resistant coating |
| Delivery | Container & Bulk freighter | End protector | 1) Plastic pipe cap 2) Iron protector |
ERW Square/Rectangular tube:
ASTM A500, API, BS, JIS, GB, DIN16219/10210. Gr. A, Gr. B, Gr. C
BS1387-85 BLACK CARBON STEEL PIPE /ERW STEEL PIPE,light serie
Casing Pipe Standards: APL 5CT oil pipe
Casing Pipe Outside diameter: 73mm to 339.7mm (2-7/8" -13-3/8 ")
length : R1,R2,R3
Type of end finish in Casing Pipe: LTC, STC, BTC, plain end
Casing Pipe Packing: bundled with steel strip
Casing Pipe Application: Casing Steel pipe serves as wall of tubing in oil drilling field.
Casing Pipe Thickness: 5.51mm to 13.84mm (0.217" -1 ")
Casing Pipe Grade: K55 J55 N80
Casing Pipe Standards: APL 5CT oil pipe
Casing Pipe Outside diameter: 73mm to 339.7mm (2-7/8" -13-3/8 ")
Casing Pipe Thickness: 5.51mm to 13.84mm (0.217" -1 ")
Casing Pipe Grade: K55 J55 N80
length : R1,R2,R3
Type of end finish in Casing Pipe: LTC, STC, BTC, plain end
Casing Pipe Packing: bundled with steel strip
Casing Pipe Application: Casing Steel pipe serves as wall of tubing in oil drilling field.
| ERW STEEL PIPE | |||||
| O.D | O.D tolerance | W.T | Thickness Tolerance | ||
| 21.34—406.4mm | ±0.03 | 0.6—30mm | ±0.02 | ||
| Length | 2—16m, according to the customers’ requirements | ||||
| International Standard | ISO9001-2000 | ||||
| Standard | ASTM A53 / BS 1387-1985 | ||||
| Material | Q195/Q215/Q235/Q345/GR.B, GR.C | ||||
| Product Category | Matallurgy, Mineral & Energy | ||||
| Technique | Welded | ||||
| Packing | In bundles or according to customers’ request | ||||
| Usage |
1 For low pressure liquid delivery such as water, gas and oil 2 For construction, e.g building greenhouse |
||||
| Main market |
Middle east, Africa, North and South America, East and West Europe, South and |
||||
| HS code | 73063090 | ||||
| Productivity | 12000ton/month | ||||
| Processing technology available | Threading, coupling and with plastic caps protected | ||||
| Remarks | 1) Payment term: T/T 2) Trade Term: FOB/CFR/CIF 3) Minimum quantity of order: 10 MT 4) Delivery period: 10 to 30 Days |
||||
Mechanical Properties (MPa) (PSL1):
Standard |
Grade | (MPa) | (MPa) | A% | ||
| API SPEC 5L |
PSL1 | |||||
| ≥ | ||||||
| psi | MPa | psi | MPa | MIN(%) | ||
| B | 35,000 | 241 | 60,000 | 414 | 21~27 | |
| X42 | 42,000 | 290 | 60,000 | 414 | 21~27 | |
| X46 | 46,000 | 317 | 63,000 | 434 | 20~26 | |
| X52 | 52,000 | 359 | 66,000 | 455 | 20~24 | |
Grade and Chemical Composition (%)
Standard |
Grade | (MPa) | (MPa) | A% | (J) | ||
| API SPEC 5L |
PSL2 | ||||||
| Min | Max | Min | Max | Min | |||
| B | 241 | 448 | 414 | 758 | 21~27 | 41(27) | |
| X42 | 290 | 496 | 414 | 758 | 21~27 | 41(27) | |
| X46 | 317 | 524 | 434 | 758 | 20~26 | 41(27) | |
| X52 | 359 | 531 | 455 | 758 | 20~24 | 41(27) | |
Mechanical Properties (MPa) (PSL2):
Standard |
Grade | Chemical Composition(%) | ||||
| C | Mn | TI | P | S | ||
| B | ≤0.24 | ≤1.20 | ≤0.04 | ≤0.025 | ≤0.015 | |
| X42 | ≤0.24 | ≤1.30 | ≤0.04 | ≤0.025 | ≤0.015 | |
| X46,X52 | ≤0.24 | ≤1.40 | ≤0.04 | ≤0.025 | ≤0.015 | |
Product Highlights
ASTM A53 A192 Boiler Tubes Cs Carbon Steel Welded Tube / Pipe Mild Carbon Detailed Product Description STANDARD ASTM,DIN,JIS,GB,SUS,TP MATERIAL Provide according to customer needs and uses TECHNIQUE Hot rolled/Cold rolled PACKAGING Export packing standard PAYMENT TT(T/T) REMARK Accept customized ...
