ASTM A179 Cold Drawn Seamless Carbon Steel Tube/DIN 2391 ST52.4 EN 10305-1 Cold Drawn Steel Tube
Product Details
| STANDARD: | JIS, AiSi, ASTM, GB, DIN, EN | MATERIAL: | TP304L |
|---|---|---|---|
| SPECIFICATION: | Carbon Steel Seamless Boiler Tube, Cold-drawn Tube, ASTM A179/seamless Boiler Tubes/seamless Steel Pipe | Package: | Standard Seaworthy Package |
| Processing: | Bending, Welding, Decoiling, Punching, Cutting, Moulding | Shape: | Round |
| Highlight |
ASTM A179 cold drawn seamless steel tube,Cold Drawn Seamless Carbon Steel Tube,A179 Cold Drawn Seamless Carbon Steel |
||
Product Description
Description
HDT specialized manufacturer of Stainless Steel Tubes for U Bend Tube Heat Ex-changer . Solution annealing after bend will be process to lower the residual stress, and followed by hydrostatic testing and dye penetrant testing if required.
Stainless Steel Tube are widely used in heat exchanger systems. Heat exchanger equipment on the basis of stainless steel tube is essential in strategically important and critical fields nuclear and petrochemical machine building.
Surface condition Finished Tube shall be free of scale, without scratches after bending
Chemistry Composition:
C, % | Mn, % | P, % | S, % |
0.06-0.18 | 0.27-0.63 | 0.035 max | 0.035 max |
Mechanical Properties:
Tensile Strength, MPa | Yield Strength, MPa | Elongation, % | Hardness, HRB |
325 min | 180 min | 35 min | 72 max |
Outside Diameter & Tolerance
Outside Diameter, mm | Tolerance, mm |
3.2≤OD＜25.4 | ±0.10 |
25.4≤OD≤38.1 | ±0.15 |
38.1＜OD＜50.8 | ±0.20 |
50.8≤OD＜63.5 | ±0.25 |
63.5≤OD＜76.2 | ±0.30 |
76.2 | ±0.38 |
Wall thickness & Tolerance
Outside Diamter, mm | Tolerance, % |
| 3.2≤OD＜38.1 | +20/-0 |
38.1≤OD≤76.2 | +22/-0 |
Application Industries
- Off-Shore Oil Drilling Companies
- Power Generation
- Petrochemicals
- Gas Processing
- Specialty Chemicals
- Pharmaceuticals
- Pharmaceutical Equipment
- Chemical Equipment
- Sea Water Equipment
- Heat Exchangers
- Condensers
Product Highlights
Description HDT specialized manufacturer of Stainless Steel Tubes for U Bend Tube Heat Ex-changer . Solution annealing after bend will be process to lower the residual stress, and followed by hydrostatic testing and dye penetrant testing if required.Stainless Steel Tube are widely used in heat ...
