Economizer SA210C Superheater Heat Exchanger Pipe Cold Drawn
Product Details
| Product Name: | Carbon Steel Pipe For Heat Exchanger SA210C | Application: | Boiler Pipe |
|---|---|---|---|
| Technique: | Cold Drawn, Cold Rolled/hot Rolled, Seamless | End Protector: | Plaint/bevel Ends With Plastic Caps |
| Thickness: | 0.2 - 60 Mm | Outer Diameter: | 13 - 1000 Mm |
| Highlight |
SA210C Heat Exchanger pipe,SA210C superheater pipe,economizer sa210c tube |
||
Product Description
Carbon Steel Pipe for Heat Exchanger SA210C SA192 for Boiler Pipe of Mediate and High Temperature Boiler Superheater
Product Introduction
ASME material, seamless steel pipe. It is mainly used for economizer, water wall and other heating surface components in boiler pressure parts; the corresponding domestic material is 20g / gb5310. The use temperature is generally lower than 450 ℃.
|
Cold Drawn Boiler Pipes Standard & Material |
ASTM A192/ASME SA192M ASTM A179/ASME SA179M ASTM A210/ASME SA210M: Grade: A1, C ASTM A213/ASME SA213M: Grade: T1, T2, T5, T9, T11, T12, T22, T23, T24, T91, T911, T92, T122 GB5310-2013: Grade: 20G, 25MnG, 15MoG, 15CrMoG, 20MoG, 12CrMoG, 12Cr2MoG, 12Cr1MoVG, 12Cr2MoWVTiB, 10Cr9Mo1VNb, 15CrMoG, 10CrMo910 DIN17175: ST35.8, ST45.8, 15Mo3, 13CrMo44, 10CrMo910, 14MoV63, 12Cr1MoV EN10216-1/2: Grade: P195GH, P235GH, P265GH, 13CrMo4-5, 10CrMo9-10, 16Mo3, 10CrMo5-5, X10CrMoVNb9-1 BS 3059: 320, 360, 440, 620-460, 629-590, 762 |
| Size | O.D: 10-76mm |
| Thickness: 0.8-12mm | |
| Length: 5.8mtr, 6mtr, 12 mtr or as per your requirement | |
| Surface Treatment | Oiled, Varnished, Black Painted |
ASTM A 192 Cold Drawn Boiler Tube Material Chemical Composition
| Chemical Composition % | |||||||
| C | Si | Mn | P | S | Cr | Ni | Cu |
| 0.06-0.18 | ≤0.25 | 0.27-0.63 | ≤0.035 | ≤0.035 | / | / | / |
ASTM A 192 Steel Mechanical Property
| Mechanical Properties | ||
|
Yield Point (Mpa) |
Tensile Point (Mpa) |
Elongation (%) |
| ≥180 | ≥325 | ≥35 |
Product Highlights
Carbon Steel Pipe for Heat Exchanger SA210C SA192 for Boiler Pipe of Mediate and High Temperature Boiler Superheater Product Introduction ASME material, seamless steel pipe. It is mainly used for economizer, water wall and other heating surface components in boiler pressure parts; the corresponding ...
