Boiler A213 P11 60X8.5mm Annealed Alloy Steel Seamless Tube
Product Details
| Product Name: | Alloy Steel Seamless Tube | Application: | Boiler And Heat Exchanger |
|---|---|---|---|
| Third Party Inspection: | SGS,BV,INTERNET ECT | Steel Grade: | P1 P2 P5 P9 P11 P22 P91 P92 T12 T22 Etc. |
| Highlight |
A213 P11 Alloy Steel Seamless Tube,8.5mm Annealed Alloy Steel Seamless Tube,Boiler P11 a213 tube |
||
Product Description
A213 P11 60 X 8.5 mm Alloy Steel Seamless Tube for Superheater&Reheater Application
-
alloy steel pipe for boiler
-
A213 P11 alloy steel pipe
-
60X 8.5 mm alloy steel pipe
- Applications: for Boilers,Superheaters,Heat-Exchangers
Size range: O.D.:6-420mm W.T.:1-50mm L: according to customer requirement
| Product Name | Alloy Steel Pipe/Tube | |
| Size | OD | 1/2"-24" |
| Thickness | sch20-sch160 | |
| Length | 5-20M | |
| Steel Material and Grade | ASTM A213 T5 T9 T11 T12 T22 ASTM A335 P5,P9,P11,P12,P22 | |
| Process Method | Cold drawn/cold rolled,Hydraulic cold drawn | |
| Standard | ASTM A450 | |
| Usage | Boiler,Superheater,and heat-exchanger,high pressure&temperature enviroment | |
| Surface | Bared Black Painting, Anti-Corrosion Coating | |
| Proctor | Plastic cap | |
| Package | Bundles, Bulk | |
| Inspection | With Hydraulic Testing, Ultrasonic testing or X-ray Test | |
| Certificate | ISO 9001-2000,ASTM 450 | |
| Date of Delivery | Less Than 15/20/25/30/40/50/60 Days According To The Quantity | |
| Payment: | L/C or T/T | |
| Port of Shipment | Shanghai,China |
|
| Steel Grade and Chemical Compositions: | |||||||
| Steel Grade | C | Mn | P | S | Si | Cr | Mo |
| max | max | max | max | max | min | ||
| P5 | 0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.50 | 4.00-6.00 | 0.45-0.65 |
| P9 | 0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.25-1.00 | 8.00-10.00 | 0.90-1.10 |
| P11 | 0.05-0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.50-1.00 | 1.00-1.50 | 0.44-0.65 |
| P12 | 0.05-0.15 | 0.30-0.61 | 0.025 | 0.025 | 0.50 | 0.80-1.25 | 0.44-0.65 |
| P21 | 0.05-0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.50 | 2.65-3.35 | 0.80-1.06 |
| P22 | 0.05-0.15 | 0.30-0.60 | 0.025 | 0.025 | 0.50 | 1.90-2.60 | 0.87-1.13 |
| P91 | 0.08-0.12 | 0.30-0.60 | 0.020 | 0.010 | 0.20-0.50 | 8.00-9.50 | 0.85-1.05 |
| P92 | 0.07-0.13 | 0.30-0.60 | 0.020 | 0.010 | 0.50 | 8.50-9.50 | 0.30-0.60 |
| Steel Grade | Tensile Strength | Yield Strength | Elongation | Hardness.Max | ||
| min.ksi [Mpa] | min.ksi [Mpa] | % | Brinell/Vickers | Rockwell | ||
| P1, P2 | 55[380] | 30[205] | 20 | |||
| P12 | 60[415] | 32[220] | 20 | |||
| P23 | 74[510] | 58[400] | 20 | |||
| P91 | 85[585] | 60[415] | 30 | 250 HB/265 HV | 25 HRC | |
| P92, P911 | 90[620] | 64[440] | 30 | 250 HB/265 HV | 25 HRC | |
| P122 | 90[620] | 58[400] | 30 | 250 HB/265 HV | 25 HRC |
|
Seamless steel tube has a hollow cross section, which is used in a large number of pipes for conveying fluids, such as pipes for oil, gas, gas, water and certain solid materials.
Compared to the steel pipe and round steel solid steel bending torsional strength phase at the same time, the weight is lighter, is a kind of economic cross section steel, widely used in the manufacture of structural and mechanical parts, such as petroleum drill pipe, auto transmission shaft, bicycle frame and construction of steel scaffolding is used with steel pipe manufacturing annular parts, such as can improve material utilization, simplifying the manufacturing process, material saving and processing time, has been widely used to make steel pipe.
