405mm ERW Pickled Stainless Steel Welded Tubes for Superheater
Product Details
| Material: | TP304 TP304L TP316 TP316L | Finishing: | Solution Annealed & Pickled |
|---|---|---|---|
| Application: | Boiler&Heat Exchanger, Superheater&Reheater, Air Preheater, Economizer | Shape: | Welded Tube |
| OD: | 8mm To 405mm | WT: | 1mm To 50mm |
| Highlight |
405mm ERW stainless steel welded tubes,ERW Pickled stainless steel welded tubes,405mm Pickled erw steel tube |
||
Product Description
ERW Stainless Steel Welded Tube Pickled For Superheater&Reheater OD 8mm To 405mm
Hua Dong Energy Technology deals with stainless steel welded pipe and tube already for more than 10 years, every
year sells more than 5,000 tons of stainless steel pipe and tube. Our client already covers for more than 30
countries. Our stainless steel seamless pipe and tube are widly used in Mining, Energy, Petrochemical,
Chemical Industry, Food plant, Paper plant, Gas and Fluid Industry etc.
| Item | Description | |
| Basic Information | Material Grade | TP304, TP304L, TP304H, TP316, TP316L, TP316Ti, TP309S, TP310S, TP321, TP321H, TP347, TP347H, etc |
| Outer Diameter | 8mm-406.4mm | |
| Wall Thickness | 1mm-50mm | |
| Length | Normally fixed length 6m, can as per customer’s requirement | |
| Standard | ASTM A312; ASTM A269; ASTM A789; ASTM A790 ect. | |
| Process Method | ERW, EFW etc | |
Application :
a) For fluid and gas transport
b) Structure and machining
c) Heat exchanger pipes etc
Advantages :
a) Superior surface finish
b) Better mechanical property
c) More precise dimension
d) Perfect inspection method and inspection equipment
Price Item :
FOB, CFR, CIF or as negotiation
Payment :
T/T, LC or as negotiation
ASTM A249 Standard :
| Size OD | Nominal Wall | Outside Diameter | Length | Wall |
| 1/2" (12.7) | 0.065" (1.65)/0.049" (1.25) | +/-0.005 (0.13) | +1/8" (3.18) - 0 | +/-10.0% |
| 3/4" (19.1) | 0.065" (1.65)/0.049" (1.25) | +/-0.005 (0.13) | +1/8" (3.18) - 0 | +/-10.0% |
| 1" (25.4) | 0.065" (1.65)/0.049" (1.25) | +/-0.005 (0.13) | +1/8" (3.18) - 0 | +/-10.0% |
| 1-1/2" (38.1) | 0.065" (1.65)/0.049" (1.25) | +/-0.008" (0.20) | +1/8" (3.18) - 0 | +/-10.0% |
| 2" (50.8) | 0.065" (1.65)/0.049" (1.25) | +/-0.008" (0.20) | +1/8" (3.18) - 0 | +/-10.0% |
| 2-1/2" (63.5) | 0.065" (1.65) | +/-0.010" (0.25) | +1/8" (3.18) - 0 | +/-10.0% |
| 3" (76.2) | 0.065" (1.65) | +/-0.010" (0.25) | +1/8" (3.18) - 0 | +/-10.0% |
| 4" (101.6) | 0.083" (2.11) | +/-0.015" (0.38) | +1/8" (3.18) - 0 | +/-10.0% |
| 6" (152.4) | 0.083" (2.11) | +/-0.030" (0.76) | +1" (25.4) - 0 | +/-10.0% |
| 6" (152.4) | 0.109" (2.77) | +/-0.030" (0.76) | +1" (25.4) - 0 | +/-10.0% |
| 8" (203.2) | 0.109" (2.77) | +0.061" (1.55)/-0.031" (0.79) | +1" (25.4) - 0 | +/-10.0% |
