ASTM213 42Crmo Cold Rolled Stainless Steel Seamless Pipe For Manifold Header
Product Details
| Steel Grade: | SAE 4130 42Crmo | Technique: | Cold Drawn |
|---|---|---|---|
| Application: | Boiler&heat Exchanger, Superheater, Reheater, Air Preheater, Economizer, Steam Drum, Manifold Header | OD: | 6-630mm |
| WT: | 1-60mm | Type: | TP304 Stainless Steel Pipe |
| Highlight |
ASTM213 cold rolled steel pipe,42Crmo cold rolled steel tube,ASTM213 Stainless Steel Seamless Pipe |
||
Product Description
TP304 TP316 ASTM312 ASTM213 Cold Rolled Stainless Steel Seamless Pipe
Stainless steel tube
Specifications:
1) Diameters: 4 - 76.2mm
2) W. T.: 0.4 - 2.5mm
3) Grades: 316L/304/304L/310S, etc.
4) Standard: GB/ISO/EN/ASTM/JIS, etc.
5) Application range: Widely use in the foodstuff, medical equipment, power, boiler, cooler, auto, condenser etc.
6) Packing: Inner packing: 1 PC/plastic bag; Outer packing: Bundles in weaving bags or in plywooden case.
| Outside path | Admission deviation |
| ≤10 | ±0.15 |
| >10~32 | ±0.20 |
| >32~50 | ±0.30 |
| >50 | ±0.8% |
| Outside path | Admission deviation |
| <25 | ±0.10 |
| ≥25~38.1 | ±0.15 |
| >38.1~50 | ±0.20 |
| ≥50~63.5 | 0.25 |
| >63.5~76 | ±0.30 |
| ≥76~102 | ±0.40 |
The thick the deviation of admission( do not include the weld sew) in wall of the weld tube is for ruling the wall thick 10% of ±, but minimum admission deviation is the 0.02 mms of ±.
The weld takes care of of settle Chinese foot length as 3 ms~9 ms, general settle the Chinese foot with the 6 ms.
The weld takes care of of settle the Chinese foot length in usually length, its the deviation of admission is the 5 mms of ±.
Adopt partial the degree of flinch in a the tube of weldfor keeping the Chinese foot measurement should not very in 2.0 mms.
The machine function sees the table 5
table 5
| Steel number | Card number | The heat handles Make degree |
The anti- pulls the strength MPa |
Accept defeat the strength MPa |
Extension rate% | Degree of hardnessHRB |
| 0Cr19N19 | 304 | ≥1010°C Nasty and cold |
≥520 | ≥205 | 40 | ≤90 |
| 00Cr19Ni11 | 304L | " " | ≥480 | ≥175 | 40 | ≤90 |
| 0Cr17Ni12M02 | 316 | " " | ≥520 | ≥205 | 40 | ≤90 |
| 0Cr17Ni14M02 | 316L | " " | ≥480 | ≥175 | 40 | ≤90 |
| 0Cr18Ni11Ti | 321 | ≥920°C Nasty and cold |
≥520 | ≥205 | 40 | ≤90 |
Hua Dong Energy Technology is one of reliable and most leading suppliers of 4130 steel materials for your different applications. Contact us for a quote or any technical queries. We’d like to hear from you.
