Name: Hot Rolled 6mm Pressure Vessel Boiler Steel Plate For Chemical Industry
Brand: ZHANGJIAGANG HUA DONG ENERGY TECHNOLOGY CO.,LTD
SKU: Steel Plate
Price: 4,900.00 USD
Availability: InStock

Home Products Boiler Alloy Steel Sheet Plate

Hot Rolled 6mm Pressure Vessel Boiler Steel Plate For Chemical Industry

Product Details:

Place of Origin:	China
Brand Name:	HDT
Certification:	ISO9001,ASME,Grade A,SGS,EN,TUV
Model Number:	Steel Plate

Payment & Shipping Terms:

Minimum Order Quantity:	5T
Price:	800 - 9000 USD / ton
Packaging Details:	seaworthy packing for exporting
Delivery Time:	60-75days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	About 10000 ton / month

Contact Now

Detailed Product Description

Product Name:	Alloy Steel Plate	Application:	Boiler
Surface:	Skin Pass	Standard:	AISI, ASTM, BS, DIN, GB, JIS, Other, ASTM
Technique:	Hot Rolled,Cold Rolled,hardfacing/Surface Welding/cladding	Surface Treatment:	Coated,Galvanized,Other
Highlight:	Hot Rolled boiler steel plate , Pressure Vessel boiler steel plate , 6mm pressure vessel steel plate

Hot Rolled 6mm Boiler Alloy Steel Sheet Plate Boiler Pressure Vessel High Strength

Applications of Boiler Alloy Steel Sheet Plate

Widely used in petroleum, chemical industry, power station, boiler and other industries. It is used in making reactors, heat exchangers, separators, spherical tanks, gas tanks, liquefied gas tanks, nuclear reactor pressure shells, boiler drums, liquefied petroleum gas cylinders, high pressure water pipes of hydropower stations, turbine shells and other equipment and components.

Product Name		Corten A/Corten B/A588 GR.A /A588 GR.B /A242
Cold Cold		0.3, 0.4, 0.5, 0.6, 0.7, 0.8, 0.9, 1.0, 1.2, 1.5mm
Hot Rolled		1.6, 2.0, 2.5, 3.0, 4.0, 5.0, 6.0, 8.0, 10, 12, 14, 16 .......40 mm
Standard		ASTM DIN GB JIS EN AISI

Product Information of Boiler Alloy Steel Sheet Plate

Continuous casting slab or primary rolling slab is used as raw material, which is heated by stepping furnace, descaled by high pressure water and then enters roughing mill. Roughing material goes through cutting head, tail and then into finishing mill for computer controlled rolling. After the final rolling, it goes through laminar cooling (computer controlled cooling rate) and coiler coil to become straight hair coil.The head and tail of straight hair roll often show the shape of tongue and fish tail, thickness, width accuracy is poor, the edge often exists wave shape, folded edge, tower shape and other defects.Its coil weight is heavy, steel coil inner diameter is 760mm.

Chemical Composition of Boiler Alloy Steel Sheet Plate

Grades	C max	Mn max	S max	P max	Si	Cr	Cu	Mo
A204 Gr A	0.18	0.90	0.035	0.035	0.15-0.40	-	-	-
A204 Gr B	0.20	0.90	0.035	0.035	0.15-0.40	-	-	-
A204 Gr C	0.23	0.90	0.035	0.035	0.15-0.40	-	-	-

Hot Rolled 6mm Pressure Vessel Boiler Steel Plate For Chemical Industry 0

Mechanical Properties of Boiler Alloy Steel Sheet Plate

Grade

Tensile Strength
(Mpa)

Yield Strength
(Mpa)

Elongation

In 100-150 mm (%)

Elongation

In 16 mm (%)

A204

440-590

220-275
