EN1.4541 Pressure Equipment Economiser Boiler Steel Tube
Product Details
| STANDARD: | JIS, AiSi, ASTM, GB, DIN, EN | MATERIAL: | TP316 |
|---|---|---|---|
| SPECIFICATION: | 321 Stainless Steel Tube 321H Stainless Steel Tube | Package: | Standard Seaworthy Package |
| Processing: | Bending, Welding, Decoiling, Punching, Cutting, Moulding | Shape: | Round |
| Highlight |
pressure equipment Boiler Steel Tube,EN1.4541 Boiler Steel Tube,EN1.4541 economiser Tubes |
||
Product Description
Boiler Steel Tube Boiler tubes - for pressure equipment, used at higher temper
Description
Boiler Tubes are metal tubes located inside of boilers that heat water in order to produce steam. There are two major types of tube boilers: water-tube boilers and fire-tube boilers. In water-tube boilers, water circulates inside the tubes and is heated externally by hot gases generated by the furnace.
Specification:
| Grade | 321 | 321H | 1.4541 |
| UNS Designation | S32100 | S32109 | |
| Carbon (C) Max. | 0.08 | 0.04–0.10 | 0.08 |
| Manganese (Mn) Max. | 2.00 | 2.00 | 2.00 |
| Phosphorous (P) Max. | 0.045 | 0.045 | 0.040 |
| Sulphur (S) Max. | 0.03 | 0.03 | 0.015 |
| Silicon (Si) Max. | 1.00 | 1.00 | 1.00 |
| Chromium (Cr) | 17.0–20.0 | 17.0–20.0 | 17.0-19.0 |
| Nickel (Ni) | 9.0–12.0 | 9.0–12.0 | 9.0–12.0 |
| Molybdenum (Mo) | — | — | |
| Nitrogen (N) | – | – | |
| Iron (Fe) | Bal. | Bal. | Bal. |
| Other Elements | Ti=5(C+N) to 0.70% | Ti=4(C+N) to 0.70% | Ti=5(C+N) to 0.70% |
A high pressure watertube boiler[1] (also spelled water-tube and water tube) is a type of boiler in which water circulates in tubes heated externally by the fire. Fuel is burned inside the furnace, creating hot gas which boils water in the steam-generating tubes. In smaller boilers, additional generating tubes are separate in the furnace, while larger utility boilers rely on the water-filled tubes that make up the walls of the furnace to generate steam.
Application Industries
- Off-Shore Oil Drilling Companies
- Power Generation
- Petrochemicals
- Gas Processing
- Specialty Chemicals
- Pharmaceuticals
- Pharmaceutical Equipment
- Chemical Equipment
- Sea Water Equipment
- Heat Exchangers
- Condensers
Product Highlights
Boiler Steel Tube Boiler tubes - for pressure equipment, used at higher temper Description Boiler Tubes are metal tubes located inside of boilers that heat water in order to produce steam. There are two major types of tube boilers: water-tube boilers and fire-tube boilers. In water-tube boilers, ...
