ASME SS316L Annealed Pickling Seamless Boiler Bank Tubes Plain Ends
Product Details
| Steel Grade: | Seamless Duplex Stainless Steel SAF 2507 UNS S32750 Duplex Steel Tube DIN1.441 | Technique: | Annealed Pickling |
|---|---|---|---|
| Application: | Petroleum,foodstuff,chemical Industry,construction, Electric Power,nuclear,energy,machinery,biotechnology,paper Making,shipbuilding,boiler Fields | OD: | 6-650MM |
| WT: | 1-52mm | Length: | 2000-12000mm |
| Highlight |
SS316L boiler bank tubes,Annealed Pickling boiler bank tubes,SS316L steam boiler tube |
||
Product Description
Part 1 . Product Description
ASME SS316L Stainless Seamless Boiler Tubes For Power Station High Safety Level
| Product Name | 2205 2507 Duplex Stainless Steel Seamless Boiler TubeS Chemical / Petrochemical Industry |
| Grade | 202 304 304L 309S 310S 316L 317L 321 347 904L 2205 2507 .etc |
| Standard | ASTM,AISI, ASME ,SUS,JIS,EN,DIN,BS,GB .etc |
| Certification | ISO,SGS, BV |
| Brand | China brand |
SIZE |
OD : 6-650 mm |
| Wall Thickness : 1-52mm | |
| Length: 6m or as your requirement | |
| Ends | 1) Plain 2) Beveled 3) Thread with Coupling or cap |
| End protector | 1) Plastic pipe cap 2) Iron protector |
| Surface Treatment | 1) Bared 2) Black Painted (varnish coating) 3) Galvanized 4) With Oiled 5) 3 PE, FBE, corrosion resistant coating |
| Payment terms | L/C TT |
| Package | Standard export packing or as per customer’s request. |
| Deliver time | 5-7 days according to quantity |
Part 2 . Applications
Chemical and petrochemical processing industries;
Oil and gas industry;
Application of fertilizer industry.
Part 3 . Products List
- stainless steel sheet /plate
- Stainless steel coil
- Stainless steel pipe/tube
- Stainless steel bar/rod
- Stainless steel square/angle bar
- Galvanized steel sheet/plate
- Galvanized steel coil
- Galvanized steel pipe/tube
Material/Grade : 304 321 316 316L 310S 309S 202 201 430 409L 444 410s 904L 2205 2507 Incoloy 800 800H 800HT 825 Inconel 600 625 718 Monel 400 Hastelloy C-276.etc
Part 4 . Packing and Shipping
Standard export packing or as per customer’s request .
Part 5 . Company Information---The Reason Why You Will Choose Us
- We are an large storage company and have our own factory . We specialize in stainless steel products for 25 years, we can supply Processing services , including cutting ,welding , surface treatment and precision processing.
- We mainly specialize in stainless steel sheet/plate/circle/coil/strip/pipe/tube/bar. etc and galvanized steel sheet/plate/coil/strip. etc . More than 200 kinds of products for your choice .
- We can also supply special stainless steel product , such as Monel / Incoloy / Inconel / Hastelloy .etc
- we have strict inspection system to ensure the quality, and all processes are carried out according to ISO 9001: 2008.
- we are nominated as the AAA enterprise by Jiangsu government.
- We are powerful manufacturer audited by world top inspection company ISO ,SGS, TUV and BV.
- Our products have been exported to more than 30 countries and regions, including
Europe,Middle East,South Asia,South America,Africa,United Arab Emirates .etc.
- The annual production capacity is 50000 tons stainless steel products.
Part 6 . Our Service
| 1 | Free samples will be available for most of the products |
| 2 | 24 hours online to ensure your inquiry will be replied within 12 hours |
| 3 | Most products can be delivered within 7 days after order |
| 4 | Small trial order can also be accepted |
| 5 | Customized Size & Surface Treatment as your requirement |
| 6 | Quality Inspection---We can provide MTC , PMI inspection , and SGS inspection or other third Party Inspection . |
| 7 | If you are not sure about what exactly you need - feel free to contact us anytime and get professional assistance from us |
Part 7 . About 2507
Alloy 32750 is a super duplex stainless steel supplied in the solution annealed condition. As a super duplex stainless steel, it combines the desirable aspects of both austenitic and ferritic grades. The higher chromium, molybdenum and nitrogen contents result in a Pitting Resistance Equivalent number (PREN) of >41, providing pitting and crevice corrosion resistance superior to austenitic and duplex stainless steels in almost all corrosive media, and a Critical Pitting Temperature exceeding 50°C.
Supplied in the annealed condition, it achieves yield strengths of 80ksi (550Mpa), greater than most austenitic and duplex stainless steel grades. It cannot be hardened by heat treatment but can be strengthened by cold working. It also exhibits a low coefficient of thermal expansion and higher heat conductivity than austenitic steels and is suitable for working temperatures up to 300°C. Alloy 32750 is listed in NACE MR 0175 for sour service and having gained ASME Approval for Pressure Vessel applications it can be used in a wide variety of applications.
hemical Composition:
| Cr | Ni | Mo | Co | Nb (+Ta) | Ti | V | W | Cu | C | Mn | N | Si | P | S | Fe | Al | |
| Min | 24.50 | 6.00 | 3.00 | 0.50 | 0.24 | 0.10 | |||||||||||
| Max | 26.00 | 8.00 | 5.00 | 0.50 | 0.03 | 1.20 | 0.32 | 0.80 | 0.035 | 0.020 | Bal |
Mechanical Properties:
| 0.2% Proof Stress | 550 N/mm2 | 79.8 ksi |
| Tensile Strength | 800 N/mm2 | 116 ksi |
| Elongation, 5.65√S0 | 25% | |
| Reduction of area | 45% | |
| Hardness (Brinell) | <270 | |
| Impact Strength (Room Temp) | 80J | |
| Impact Strength (-46oC) | Longitidinal 45J (35J min) | |
| Transverse 45J (35J min) | ||
Notes:
- Testing shall be carried out in accordance with ASTM A370 or EN ISO 6892-1 (tensile), EN ISO 6506-1 (hardness)
- Minimum properties quoted (tested at room temperature in a longitudinal direction)
- Testing performed on each melt of material per heat treatment batch
- Hardness shall be in accordance with NACE MR 1075 with a maximum HRC of 25
- ASTM G48A corrosion test (at 50°C) No pitting and < 3.0g/m2 weight loss (ASTM specification < 4.0g/m2)
- Ferrite content 35-55%
- Microstructure certified free from grain boundary carbides, sigma, chi and laves phases
Physical Properties:
| Density (Kg/m3) | 7810 |
| Magnetic Permeability (20°C) | 33 |
| Young’s Modulus (kN/mm2) | 199 |
| Specific Electrical Resistance, 20°C (µΩ.m) | 0.8 |
| Mean coefficient of thermal expansion, 20-300°C (m/m/oC) | 11.1 x 10-6 |
| Specific Heat, 20°C (J/kg.K) | 475 |
| Thermal conductivity, 20°C (W/m.K) | 14.2 |
