GB 350kW Organic Heat Carrier Boiler for Chemical industry
Product Details
| Product Name: | Gas/Oil Organic Heat Carrier Boiler | Material Of Tubes Inside: | 20 GB3087 |
|---|---|---|---|
| Application: | Petrochemical, Chemical, Printing, Food | Keywords: | Heat Transfer Oil Boiler |
| Rated Power: | 350kW | Design Pressure: | 1.1 Mpa |
| Highlight |
GB Organic Heat Carrier Boiler,350kW Organic Heat Carrier Boiler,350kW carrier steam boiler |
||
Product Description
YYW-350Y/Q Gas-fired/Oil-fired Organic Heat Carrier Boiler in ASME/GB Standard
Product Introduction:
Structure Features of This Series of Products:
- The boiler surface adopts the tightening-tube-arrangement with spiral structure. The chimney adopts the three-pass arrangement.
- An air preheater or a water/steam transformer is arranged behind the boiler, reducing the temperature, improving the thermal efficiency of the boiler.
- The quick opening door or the observation door is equipped for the convenience of checking the internal inspection and maintenance.
Oil/Gas Thermal Boiler System Diagram
Prodcut Range:
Rated thermal power: 0.7MW - 29MW (60xl04Cal/hr - 2500xl04Cal/hr)
Design pressure: 0.6MPa - 1.6MPa
Specific parameters are shown in the table below.
Some Models Specification:
| Model | YYL(W)-350Y, Q | YYL(W)-600Y, Q | YYL(W)-700Y, Q | YYL(W)-900Y, Q | YYL(W)-1200Y, Q | YYL(W)-1500Y, Q | YYL(W)-1800Y, Q | |
| Rate power (kW) | 350 | 600 | 700 | 900 | 1200 | 1500 | 1800 | |
| Heating capacityx10000 (kCal/h) | 30 | 50 | 60 | 75 | 100 | 130 | 150 | |
| Fuel thermal efficiency | ≧90 | ≧90 | ≧90 | ≧90 | ≧90 | ≧90 | ≧90 | |
| Gas thermal efficiency | ≧92 | ≧92 | ≧92 | ≧92 | ≧92 | ≧92 | ≧92 | |
| Design pressure (Mpa) | 1.1 | 1.1 | 1.1 | 1.1 | 1.1 | 1.1 | 1.1 | |
| Max. working temperature (℃) | 320 | 320 | 320 | 320 | 320 | 320 | 320 | |
| Medium circulation (m3/h) | 40 | 60 | 60 | 100 | 100 | 100 | 100 | |
| Medium capacity in a furnace (m3) | 0.24 | 0.7 | 0.7 | 0.7 | 0.8 | 0.95 | 2.1 | |
| Supervisor diameter (DN) | 80 | 100 | 100 | 125 | 125 | 125 | 150 | |
| Installed capacity (kW) | 12 | 22 | 23 | 30 | 40 | 42 | 57 | |
| Applicable fuel | oil,gas | |||||||
| Fuel consumption Kg/hl(light oil)/Nm3/h(natural gas) | 32.6/38.5 | 56/66 | 65.3/77 | 84/99 | 112/132 | 140/165 | 168/198 | |
| Size long x wide x high (m) | Vertical boiler | 1.97x1.76x3.1 | 1.97x1.76x3.2 | 1.97x1.76x3.2 | 3.5x1.76x3.2 | 4.64x2.9x2.125 | 3.11x2.17x5.27 | 5.7x2.55x2.8 |
| Horizontal boiler | 2.3x1.65x1.5 | 3.15x1.95x1.84x3.15x1.95x1.84 | 3.6x2.1x2 | 4.05x2.13x2.07 | 4.4x2.15x2.13 | 4.94x2.2x2.8 | ||
| Model | YYL(W)-2300Y,Q | YYL(W)-2900Y,Q | YYL(W)-3500Y,Q | YYL(W)-4100Y,Q | YYL(W)-4700Y,Q | YYL(W)-5900Y,Q | |
| Rated power(kW) | 2300 | 2900 | 3500 | 4100 | 4700 | 5900 | |
| Heating capacityx104(kCal/h) | 200 | 250 | 300 | 350 | 400 | 500 | |
| Fuel thermal efficiency | ≥90 | ≥90 | ≥90 | ≥90 | ≥90 | ≥90 | |
| Gas thermal efficiency | ≥92 | ≥92 | ≥92 | ≥92 | ≥92 | ≥92 | |
| Disign pressure(Mpa) | 1.1 | 1.1 | 1.1 | 1.1 | 1.1 | 1.1 | |
| Max. working temperarure(°C) | 320 | 320 | 320 | 320 | 320 | 320 | |
| Medium circulation(m3/h) | 160 | 200 | 200 | 200 | 260 | 300 | |
| Medium Capacity in Furnace(m3) | 2.4 | 2.9 | 3.2 | 4.1 | 5.6 | 8.8 | |
| Supervisor diameter(DN) | 150 | 200 | 200 | 200 | 200 | 250 | |
| Installed capacity(kW) | 60 | 74 | 78 | 78 | 101 | 124 | |
| Applicable fuel | Oil, gas | ||||||
| Fuel consumption Kg/h(light oil) /Nm3/h(natural gas) | 214.5/253 | 270.4/319 | 326/385 | 382/451 | 438/517 | 550/649 | |
| Size long X wide X high(m) | Vertical boiler | 2.9X3.1X6.4 | 6x3.1x2.98 | 5.86X3.44X3.08 | 3.15X347X615 | 6.49X3.44X3.08 | 7.45x3.65x3.45 |
| Harizontal boiler | 5.5X2.8X2.9 | 6.5X2.88X2.65 | 6.8X3X3.15 | 7.2X3.31X3.25 | 7X3.5X3.25 | 8.2X4X3.46 | |
Product Highlights
YYW-350Y/Q Gas-fired/Oil-fired Organic Heat Carrier Boiler in ASME/GB Standard Product Introduction: Structure Features of This Series of Products:The boiler surface adopts the tightening-tube-arrangement with spiral structure. The chimney adopts the three-pass arrangement.An air preheater or a ...
