YYL Type ASME Horizontal Oil Gas Boiler Tightening Tube Arrangement
Product Details
| Rated Thermal Power: | 0.7MW - 29MW (60xl04Cal/hr - 2500xl04Cal/hr) | Design Pressure: | 0.6MPa - 1.6MPa |
|---|---|---|---|
| Types: | Horizontal | Feature: | High Effiency |
| Material: | Top Grade Quality Raw Materials&Electrical Parts | Dimension: | According To Customer's Requirements |
| Highlight |
YYL Horizontal oil gas boiler,ASME oil gas boiler,ASME oil fired steam boiler |
||
Product Description
Product Type
YYL(W) type horizontal type fuel oil(gas) heat boiler
Product Range
Rated thermal power: 0.7MW - 29MW (60xl04Cal/hr - 2500xl04Cal/hr)
Design pressure: 0.6MPa - 1.6MPa
Specific parameters are shown in Table6
Our Company
Founded in 1985, Zhangjiagang Hua Dong Boiler Co., Ltd is a professional manufacturing company for boiler and pressure vessel. Our company covers an area of more than 100,000 square meters, with more than 500 workers and more than 150 engineering technicians of various types. Our company holds "S" and "U" stamps of ASME (American Society of Mechanical Engineers) standards, Class-A Boiler Manufacturing License, D1D2 Pressure Vessel Manufacturing License of China. We have established and maintained a Quality Management System certified according to the international Quality Standard ISO9001. Hua Dong has developed a series of progress technologies in the field of manufacturing of boiler and pressure vessel With about 36 years' technical accumulation and innovation. Hua Dong has more than 100 invention patents and utility model patents in such aspects as boiler combustion, heat transfer and structure. The boiler products of Hua Dong include: power boiler, steam boilers, hot-water boilers, organic thermal oil boilers which fueled by the combustion of oil, natural gas, coal, biomass, electric heating, waste-heat, etc. Products are widely used in power generation, heating, chemical industry, textile industry, food industry, paper industry, pavement, plastice, rubber, wood, etc.. Our products not only serve well for all over China, but also are exported to such countries / regions as USA, Japan, Australia, Russia, Vietnam, Philippine, Malaysia, Indonesia, Pakistan, Kazakhstan, Egypt, and Africa.
Structural features of this series of products
- There are two types of structure: vertical(YYL) and horizontal(YYW).
- The boiler surface adopts the tightening-tube-arrangement with spiral structure. The chimney adopts the three-pass arrangement.
- An air preheater or a water/steam transformer is arranged behind the boiler, reducing the temperature, improving the thermal efficiency of the boiler.
- The quick opening door or the observation door is equipped for the convenience of checking the internal inspection and maintenance.
-
Technical Parameter
Cement production line capacity t/d 1000 2500 5000 10000 Boiler inlet flow Nm3/h Kiln(front) 60000 88000 243000 472000 Kiln(tail) 76000 170000 328000 612000 Boiler inlet gas temperature℃ Kiln(front) 370 360 380 390 Kiln(tail) 360 320~360 330 330 Rated evaporation t/h Kiln(front) 5.8 7.25 24 50 Kiln(tail) 7.5 10~15.8 20~24.6 35.5 Rated steam pressure Mpa Kiln(front) 1.25 1.25 1.25 1.25 Kiln(tail) 1.25 1.25 1.25 1.25 Rated steam temperature℃ Kiln(front) 340 330 350 360 Kiln(tail) 340 300~340 310 310 Boiler structure Kiln(front) Vertical Vertical Vertical Vertical Kiln(tail) Vertical Vertical and Horizontal Vertical and Horizontal Vertical
Oil/Gas Thermal Boiler System Diagram
Parameters Table 6
