High Pressure SA192 Boiler Steel Tube For Power Station Maintenance
Product Details
| Product Name: | Seamless Carbon Steel Boiler Tube | Application: | For High, Middle, Low Pressure Boiler And Pressure Purpose |
|---|---|---|---|
| Standard: | ASTM A192 High Pressure Steel Tube | Technique: | Seamless |
| Section Shape: | Round | Material: | Carbon Steel |
| Highlight |
High Pressure SA192 Steel Tube,SA192 Power Station Steel Tube,ASTM A192 High Pressure Steel Tube |
||
Product Description
Seamless Carbon Steel Boiler Tube High Pressure SA192 For Power Station Maintenance
A192/SA192 SMLS Carbon Steel Tube For High, Middle , Low Pressure Boiler And Pressure Purpose
Detail:
Standard: ASTM A192/SA192SMLS
Size:(mm)
Out Dimensions: 12.7mm – 114.3mm
Wall Thickness: 0.8mm - 15mm
Length: Fixed(6m,9m,12,24m) or normal length(5-12m)
Description:
ASTM ASTM A192 SMLS
Seamless Carbon Steel Boiler Tubes For High-Pressure Service.
Steel Grde:
Grade A
Packing:
Beveled/black painting/ plastic caps/ in bundles/ steel strips/ wooden protection
Inspection and Test:
Chemical Composition Inspection, Mechanical Properties Test(Tensile Strength, Yield Strength,Elongation, Flaring, Flattening, Bending, Hardness, Impact Test),Surface and Dimension Test,Nodestructive Test, Hydrostatic Test.
Surface treatment:
Oil-dip, Varnish, Passivation, Phosphating, Shot Blasting
Mark:
As requested.
Delivery Condition:
Annealed, Normalized, Normalized and Tempered
Chemical composition:
| Product | Ttem | Grade | Chemical composition | |||||||
| C | Si | Mn | P.≤ | S.≤ | Cr | Ni | others | |||
| Carbon steel | 1 | 10 | 0.07/0.13 | 0.17/0.37 | 0.35/0.65 | 0.03 | 0.03 | ≤0.15 | ≤0.30 | Cu≤0.25 |
| 2 | 20 | 0.17/0.23 | 0.17/0.37 | 0.35/0.65 | 0.03 | 0.03 | ≤0.25 | ≤0.30 | Cu≤0.25 | |
| 3 | A179 | 0.06/0.18 | - | 0.27/0.63 | 0.03 | 0.03 | - | - | - | |
| 4 | A192 | 0.06/0.18 | ≤0.25 | 0.27/0.63 | 0.03 | 0.03 | - | - | - | |
Mechanical properties:
| Item | Mark | Tensile property | Hardness | ||||
| Extension strength Rm Mpa | Lower Yield strength Rel or Rp0.2 MPa | lower Yield strength ReL or Rp0.2 Mpa | |||||
| Thickness | Thickness | ||||||
| ≤16 | >16 | <5.1 | ≥5.1 | ||||
| ≥ | ≤ | ||||||
| 1 | 10 | 335~475 | 205 | 195 | 24 | - | - |
| 2 | 20 | 410~530 | 245 | 235 | 20 | - | - |
| 3 | A179 | ≥325 | 180 | 35 | - | - | |
| 4 | A192 | ≥325 | 180 | 35 | 77HRB | 137HB | |
Applications:
1, For evaporator, heat exchangers, condensers, heat transfer equipment and similar pipes.
2, Widely used in the mechanical treatment field, petrochemical industry, transport and construction field
3, Ordinary structural purposes and mechanic structural purposes, for example in construction field, fulcrum bearing etc;
4, The transportation of fluids in the projects and big equipments, for example transport of water, oil, gas etc
5, Can be used in low and medium pressure boiler for the transportation of fluids, for example steam tube, big smoke tube, small smoke tube, generating tube etc
Inspection and Test:
Chemical Composition Inspection, Mechanical Properties Test(Tensile Strength,Yield Strength,
Elongation, Flaring, Flattening, Bending, Hardness, Impact Test), Surface and Dimension Test,No-destructive Test, Hydrostatic Test.
Surface treatment:
Oil-dip, Varnish, Passivation, Phosphating, Shot Blasting
Product Highlights
Seamless Carbon Steel Boiler Tube High Pressure SA192 For Power Station Maintenance A192/SA192 SMLS Carbon Steel Tube For High, Middle , Low Pressure Boiler And Pressure Purpose Detail: Standard: ASTM A192/SA192SMLS Size:(mm) Out Dimensions: 12.7mm – 114.3mm Wall Thickness: 0.8mm - 15mm Length: ...
