Seamless Boiler Steel Tube Schedule 40 Dry Varnish Coated A53 Carbon Steel
Product Details
| Standard: | API/CE / ISO /TUV | Product Name: | Carbon Steel Pipe Boiler Tube For Heat Exchanger |
|---|---|---|---|
| Application: | Industrial Boiler | Surface Treatment: | Dry Varnish Coated |
| Secondary Or Not: | Non-secondary | Technique: | Seamless |
| Highlight |
Seamless Boiler Steel Tube,Carbon Steel Pipe Boiler Tube,Dry Varnish Coated Boiler Steel Tube |
||
Product Description
Boiler Tube ASME Seamless Schedule 40 A106 A53 Carbon Steel
|
Equivalent Designation
|
|||||
| DIN | EN | BS | NFA | ASTM | ASME |
| – | EN P235GH Grade 10216-2 | – | ASTM A179 – | ASME SA 179 – | UNI C14 |
ASME SA 210A1 specification covers minimum-wall-thickness, seamless cold-drawn low-carbon steel tubes for tubular heat exchangers, condensers, and similar heat transfer apparatus. Recommended pipe size will be developed by FerroPipe upon receipt of your inquiry. A print or sketch of the part to be produced should be included. Grade, chemical analysis and surface condition are carefully considered, and production processes are tailored to achieve the best tubing for the end use.
ASME SA 210A1 Carbon Steel Seamless Tubes stockist in China
hdt Pipeline stocks a complete range of IBR Certified ASME SA210a1 bon Steel Seamless Tubes in outer diameter tube sizes ½”-24” and Nominal bore NB sizes 15NB-600NB in Mumbai, India.
Exporting Carbon Steel Pipes and Alloy Steel Pipes to countries worldwide including IRAN, IRAQ, KUWAIT, QATAR, South Africa, Nigeria, Saudi Arabia, Australia, Canada & Mexico.
The Manufacturer shall provide Material Test certificate of inspection to the purchaser stating that the material has been manufactured, sampled, tested, and inspected in accordance with ASME SA 210a1cluding year of issue), and has satisfied all the requirements of ASME SA 210a1
Pipes and Tubes manufactured as per ASME SA 210a1 certified with En 10204 Type 3.1/3.2. IBR,NACE,HIC,IGC,IMPACT are adhered as supplementary testing requirements.
Carbon Steel Seamless Pipes Details
| Commodity | carbon steel seamless pipe |
| O.D. | 6mm - 660.4mm |
| Wall Thickness | 1-80mm |
| Length | 1-12m random length, 5.8m, 6m, 11.8m, 12m fixed length or as required |
| Standard | DIN17175, ASTM A53, ASTM A106, ASTM A333 |
| Material | ST37 ST52 A106 A53 10# 20# 45# |
| Application | Widely be used in costruction, chemical, boiler, gas and oil fields |
| Surface | Black painting, varnish paint, anti rust oil, 3PE, etc. |
| Package | Plastic caps on both ends, Steel bundle, Woven bag or acc. to customers' request |
| Certificate | API, ISO, SGS, MTC |
| Capacity | 50000 tons/year |
| Advantage |
1.Reasonable price with excellent quality 2.Abundant stock and prompt delivery 3.Rich supply and export experience, sincere service |
Material Grades
| High Temperature Seamless Pipe | ASTM A106 Gr. B/C, API 5L Gr. B, ASTM A53 Gr. B |
| Heat Exchanger Seamless Tube | ASTM A179 |
| Low Temperature Seamless Pipe | ASTM A333 Gr. 3/6 |
| Low Temperature Seamless Tube | ASTM A334 Gr. 6 |
| High Yield Seamless Pipe | API 5L Gr. X42/X46/X52/X56/X60/X65/X70/X80 PSL-1/PSL-2 |
| High Yield Seamless Pipe | ISO 3183 Gr.L245, L290, L320, L360, L390, L415, L450, L485 |
| Atmospheric & Low Temp EFW Pipes | ASTM A671 Gr. CC60/CC65/CC70 |
| High Pressure & Moderate Temp EFW Pipes | ASTM A672 Gr. B60/B65/B70/C55/C60/C65/C70 |
| High Yield ERW/SAW Pipe | API 5L Gr. X42/X46/X52/X56/X60/X65/X70/X80 PSL-1/PSL-2 |
| High Yield ERW/SAW Pipe | ISO 3183 Gr.L245, L290, L320, L360, L390, L415, L450, L485 |
Additional Testing : NACE MR0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc.
Dimensions : All Pipe is manufactured and inspected/tested to the relevant standards including ASTM, ASME, API.
| High Temperature Seamless Pipe | ASTM A106 Gr. B/C, API 5L Gr. B, ASTM A53 Gr. B |
| Heat Exchanger Seamless Tube | ASTM A179 |
| Low Temperature Seamless Pipe | ASTM A333 Gr. 3/6 |
| Low Temperature Seamless Tube | ASTM A334 Gr. 6 |
| High Yield Seamless Pipe | API 5L Gr. X42/X46/X52/X56/X60/X65/X70/X80 PSL-1/PSL-2 |
| High Yield Seamless Pipe | ISO 3183 Gr.L245, L290, L320, L360, L390, L415, L450, L485 |
| Atmospheric & Low Temp EFW Pipes | ASTM A671 Gr. CC60/CC65/CC70 |
| High Pressure & Moderate Temp EFW Pipes | ASTM A672 Gr. B60/B65/B70/C55/C60/C65/C70 |
| High Yield ERW/SAW Pipe | API 5L Gr. X42/X46/X52/X56/X60/X65/X70/X80 PSL-1/PSL-2 |
| High Yield ERW/SAW Pipe | ISO 3183 Gr.L245, L290, L320, L360, L390, L415, L450, L485 |
Additional Testing : NACE MR0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc.
Dimensions : All Pipe is manufactured and inspected/tested to the relevant standards including ASTM, ASME, API.
