600mm Heat Exchanger A269 Seamless Stainless Steel Tubing

600mm Heat Exchanger A269 Seamless Stainless Steel Tubing

  • 600mm Heat Exchanger A269 Seamless Stainless Steel Tubing
  • 600mm Heat Exchanger A269 Seamless Stainless Steel Tubing
  • 600mm Heat Exchanger A269 Seamless Stainless Steel Tubing
  • 600mm Heat Exchanger A269 Seamless Stainless Steel Tubing
600mm Heat Exchanger A269 Seamless Stainless Steel Tubing
Product Details:
Place of Origin: China(Mainland)
Brand Name: HDT
Certification: EN10216-5 , A213, A269, A789 , A790
Model Number: TP304, TP304L, TP304H, TP304N , TP309S, TP310S, TP310H , TP316L , TP316H, TP316Ti, TP317L, TP321H, TP347H , TP904L
Payment & Shipping Terms:
Minimum Order Quantity: 20 tons
Price: 5000 - 10000 USD per ton
Packaging Details: seaworthy packing for exporting
Delivery Time: 60-75days after getting the down payment or L/C
Payment Terms: L/C at sight, T/T,, Western Union
Supply Ability: About 5000 tons per month
Contact Now
Detailed Product Description
Material: TP304, TP304L, TP304H, TP304N , TP309S, TP310S, TP310H , TP316L , TP316H, TP316Ti, TP317L, TP321H, TP347H , TP904L Finishing: Solution Annealed & Pickled
Application: Heat Exchanger, Boiler, Condenser, Energy, Mining Shape: U Bend, Straight
OD: 6.00mm To 600mm WT: 0.5mm To 50mm
Highlight:

A269 seamless stainless steel tubing

,

600mm seamless stainless steel tubing

,

600mm seamless heat exchanger tubing

Stainless Steel Seamless Pipe, Pickled, Solid, Annealed ASTM A269 TP304 , ASME SA269 TP304L

NOS ENCANTARíA APOYARLES EN LENGUA ESPAÑOLA SI TIENEN CUALQUIER REQUERIMIENTO RELATIVO!



Hua Dong Energy Technology has more than 35 years experiences for heat exchanger pipe/boiler pipe,

Our main products: Stainless/Nickel Alloy Pipe:

1>.A:Stainless Steel Grade: TP304/304L/304H, TP310S/310H, TP316/316L/316Ti/316H, TP317L/317LN, TP321/321H, TP347/347H, NO8904(904L),

B:PH Stainless Steel:17-4PH(1.4542), 17-7PH(1.4568),15-7PH(1.4532)

C:Nickel Alloy Steel Grade:Hestalloy:C-276, C-4, C-22, C-2000, X, B-2, B-3, G-30, G-35. Monel:400,401, 404, R-405, K500.

Inconel:600, 601, 617, 625, 690, 718, 740, X-750. Incoloy:800, 800H, 800HT, 825, 840.

Pure Nickel:Ni-200, Ni-201, Ni-270. NS Alloy:Ns 1101, NS1102, NS1103,NS3105.

2>. Standards: ASTM A213, A249, A269, A312, A789,A790, B163,B167, B444, B677,... and ASME,DIN, EN, JIS, BS, GOST,...

3>. Out diameter sizes range: 0.5mm~650mm. Wall thickness:0.05mm~60mm. Max. length under 26 meters/PC.
4>. Seamless & welded, Solution Pickling/Bright Annealed / Polished.



Advantage Products: (Boiler & Heat Exchanger & Condenser Pipe):

ASTM A213(TP304,TP304L,TP304H,TP310S,TP316L,TP316Ti, TP317/L, TP321/H, TP347/H)

ASTM A249(TP304,TP304L,TP316L, TP321/H)
ASTM A789(S31803(2205), 32750(2507), S31254(254MO),S32304)

ASTM B163/B167/B444 for Nickel Alloy Steel Pipe

ASTM B677 UNS NO8904(904L)

ASTM B111(70400, C70600, C71500, C71640, C68700, C44300)

Other Standard: EN10216-5, DIN 17456, DIN17458, GOST9941-81, JIS-G3459, JIS-G3463



Grade Material
number
C Si Mn P S N Cr Mo Ni Ti others
Ferritic or martensitic steels
X2CrTi12 1.4512 600mm Heat Exchanger A269 Seamless Stainless Steel Tubing 00.030 1.00 1.00 0.040 0.015   10.50to12.50     6×(C+N)to0.65
X6CrAl13 1.4002 600mm Heat Exchanger A269 Seamless Stainless Steel Tubing 00.08 1.00 1.00 0.040 0.015   12.00to14.00       0.10to0.30Al
X6Cr17 1.4016 600mm Heat Exchanger A269 Seamless Stainless Steel Tubing 00.08 1.00 1.00 0.040 0.015   16.00to18.00
X3CrTi17 1.4510 600mm Heat Exchanger A269 Seamless Stainless Steel Tubing 00.05 1.00 1.00 0.040 0.015   16.00to18.00     4×(C+N)+0.15 to 0.80
X12Cr13 1.4006 0.08 to 0.15 1.00 1.50 0.040 0.015   11.50to13.50   600mm Heat Exchanger A269 Seamless Stainless Steel Tubing 00.75
Austenitic steels
X5CrNi18-10 1.4301 600mm Heat Exchanger A269 Seamless Stainless Steel Tubing 00.07 1.00 2.00 0.045 0.015 600mm Heat Exchanger A269 Seamless Stainless Steel Tubing 00.11 17.00to19.50   8.00to10.50
X2CrNi19-11 1.4306 600mm Heat Exchanger A269 Seamless Stainless Steel Tubing 00.030 1.00 2.00 0.045 0.015 600mm Heat Exchanger A269 Seamless Stainless Steel Tubing 00.11 18.00to20.00   10.00to12.00
X2CrNiN18-10 1.4311 600mm Heat Exchanger A269 Seamless Stainless Steel Tubing 00.030 1.00 2.00 0.045 0.015 0.12to0.22 17.00to19.50   8.50to11.50
X6CrNiTi18-10 1.4541 600mm Heat Exchanger A269 Seamless Stainless Steel Tubing 00.08 1.00 2.00 0.045 0.015   17.00to19.00   9.00to12.00 5×C to 0.70
X6CrNiNb18-10 1.4550 600mm Heat Exchanger A269 Seamless Stainless Steel Tubing 00.08 1.00 2.00 0.045 0.015   17.00to19.00   9.00to12.00   10×Cto1.00Nb
X5CrNiMo17-12-2 1.4401 600mm Heat Exchanger A269 Seamless Stainless Steel Tubing 00.07 1.00 2.00 0.045 0.015 600mm Heat Exchanger A269 Seamless Stainless Steel Tubing 00.11 16.50to18.50 2.00to2.50 10.00to13.00
X2CrNiMo17-12-2 1.4404 600mm Heat Exchanger A269 Seamless Stainless Steel Tubing 00.030 1.00 2.00 0.045 0.015 600mm Heat Exchanger A269 Seamless Stainless Steel Tubing 00.11 16.50to18.50 2.00to2.50 10.00to13.00
X6CrNiMoTi17-12-2 1.4571 600mm Heat Exchanger A269 Seamless Stainless Steel Tubing 00.08 1.00 2.00 0.045 0.015   16.50to18.50 2.00to2.50 10.50to13.50 5×C to 0.70
X2CrNiMoN17-13-3 1.4429 600mm Heat Exchanger A269 Seamless Stainless Steel Tubing 00.030 1.00 2.00 0.045 0.015 0.12to0.22 16.50to18.50 2.50to3.00 11.00to14.00
X2CrNiMo18-14-3 1.4435 600mm Heat Exchanger A269 Seamless Stainless Steel Tubing 00.030 1.00 2.00 0.045 0.015 600mm Heat Exchanger A269 Seamless Stainless Steel Tubing 00.11 17.00to19.00 2.50to3.00 12.50to15.00
X3CrNiMo17-13-3 1.4436 600mm Heat Exchanger A269 Seamless Stainless Steel Tubing 00.05 1.00 2.00 0.045 0.015 600mm Heat Exchanger A269 Seamless Stainless Steel Tubing 00.11 16.50to18.50 2.50to3.00 10.50to13.00
X2CrNiMoN17-13-5 1.4439 600mm Heat Exchanger A269 Seamless Stainless Steel Tubing 00.030 1.00 2.00 0.045 0.015 0.12to0.22 16.50to18.50 4.00to5.00 12.50to14.50

























































































Specification:

ASME SA213/A213: Standard Specification for Seamless Ferritic and Austenitic Alloy-

Steel Boiler, Superheater and Stainless Steel Heat Exchanger Pipes.



ASTM A249 / A249M:Standard Specification for Welded Austenitic Steel Boiler, SuperheaterHeat-Exchanger, and Condenser Pipes.





Material Grade:

American Standard

Austenitic Steel:

TP304,TP304L,TP304H, TP304N, TP310S,TP316,TP316L,TP316Ti,TP316H, TP317,TP317L, TP321, TP321H,TP347, TP347H,904L…

Others:TP405,TP409, TP410, TP430, TP439,...

Europen Standard 1.4301,1.4307,1.4948,1.4541,1.4878,1.4550,1.4401,1.4404,1.4571,1.4438, 1.4841,1.4845,1.4539,1.4162, 1.4462, 1.4362, 1.4410, 1.4501
Russia Standard 08Х17Т,08Х13,12Х13,12Х17,15Х25Т,04Х18Н10,08Х20Н14С2, 08Х18Н12Б,10Х17Н13М2Т,10Х23Н18,08Х18Н10,08Х18Н10Т, 08Х18Н12Т,08Х17Н15М3Т,12Х18Н10Т,12Х18Н12Т,12Х18Н9, 17Х18Н9, 08Х22Н6Т, 06ХН28МДТ





Size Range:

Production Outside Diameter Wall Thickness
Heat Exchanger Tube 6.00mm to 600mm 0.5mm to 50mm





Final Finishing

Solution Annealed & Pickled/Bright Annealed.



600mm Heat Exchanger A269 Seamless Stainless Steel Tubing 23600mm Heat Exchanger A269 Seamless Stainless Steel Tubing 24600mm Heat Exchanger A269 Seamless Stainless Steel Tubing 25600mm Heat Exchanger A269 Seamless Stainless Steel Tubing 26

Type of Tubes:

Coil, U-bend & Straight.
