316L Bright Annealed Stainless Steel U Bend Pipe Mirror Polished

Product Details:

Place of Origin:	China(Mainland)
Brand Name:	HDT
Certification:	ASME, TUV, ISO9001, ASTM A213/A213M-2013
Model Number:	TP304/304L , TP316L , TP310S, TP316Ti, TP321/321H , TP347

Payment & Shipping Terms:

Minimum Order Quantity:	5T
Price:	800 - 9000 USD / ton
Packaging Details:	seaworthy packing for exporting
Delivery Time:	60-75days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	About 10000 ton / month

Contact Now

Detailed Product Description

Material:	TP304/304L , TP316L , TP310S, TP316Ti, TP321/321H , TP347	Finishing:	Annealed & Pickled
Application:	Boiler, Economizer, Superheater, Air Preheater	Color:	Customized
OD:	6.00mm To 830mm	WT:	0.5mm To 52mm
Highlight:	316L stainless steel u bend , Annealed stainless steel u bend , 316L ss bend pipe

Bright Annealed 304 304L 316L Mirror Polished Stainless Steel Pipe Sanitary Piping U Bend Straight

Stainless steel pipe is a hollow long round steel, which is widely used in petroleum, chemical, medical, food, light industry,
mechanical instrumentation and other industrial pipelines and mechanical structural parts. In addition, when the bending and torsion strength are the same, the weight is lighter, so it is also widely used in the manufacture of mechanical parts and engineering structures. Also often used as furniture and kitchen utensils.

Product Name	Stainless Steel Pipes
type	welded & seamless
material	200 series: 201/202 300 series: 301/304/304L/305/309S/316/316L/316LN/316Ti/310S/347/347H 400 series: 405/409/409L/410/420/430/440C/444/447 Super stainless steel: 904L duplex stainless steel: 2205/2507/2520 600 series: 630/631
Size	1/2”-24”,OD:21.3mm-610mm
Wall thickness	SCH5S,SCH10S,SCH40S,STD,XS,XXS,SCH20,SCH30,SH40,SCH60, SCH80,SCH160,XXS and etc.
standard	ASTM GB EN DIN AISI JIS
surface treatment	polished/hairline/stain/pickling
features	100% recycled/enviromental-friendly/durable/anti oxidation/anti corrosion/high temperature resistance/wear resistant/long lifetime/Not easy to accumulate bacteria/healthy
Application	Mainly used in petroleum, chemical, medical, food, light industry, mechanical instrument and other industrial pipeline and mechanical structure parts. it is also widely used in the manufacture of mechanical parts and engineering structures.Also commonly used for the production of various conventional weapons, barrels, shells, etc. it is also used in construction and to make railing
MOQ	1 ton
price term	CIF FOB EXW DDP DDU CFR
payment term	under $10,000, you need pay in full by T/T over $15,000, 30%TT deposit in advance and 70%T/T the balance before shipment
other service	1. sample is available 2. we support face-to-face video inspection and third party SGS inspection

Chemical Composition

Grade	C	Si	Mn	P	S	Ni	Cr	Mo
201	≤0 .15	≤0 .75	5. 5-7. 5	≤0.06	≤ 0.03	3.5 -5.5	16 .0 -18.0	-
202	≤0 .15	≤l.0	7.5-10.0	≤0.06	≤ 0.03	4.0-6.0	17.0-19.0	-
301	≤0 .15	≤l.0	≤2.0	≤0.045	≤ 0.03	6.0-8.0	16.0-18.0	-
302	≤0 .15	≤1.0	≤2.0	≤0.035	≤ 0.03	8.0-10.0	17.0-19.0	-
304	≤0 .0.08	≤1.0	≤2.0	≤0.045	≤ 0.03	8.0-10.5	18.0-20.0	-
304L	≤0.03	≤1.0	≤2.0	≤0.035	≤ 0.03	9.0-13.0	18.0-20.0	-
309S	≤0.08	≤1.0	≤2.0	≤0.045	≤ 0.03	12.0-15.0	22.0-24.0	-
310S	≤0.08	≤1.5	≤2.0	≤0.035	≤ 0.03	19.0-22.0	24.0-26.0
316	≤0.08	≤1.0	≤2.0	≤0.045	≤ 0.03	10.0-14.0	16.0-18.0	2.0- 3.0
316L	≤0 .03	≤1.0	≤2.0	≤0.045	≤ 0.03	12.0 - 15.0	16 .0 -1 8.0	2.0 - 3.0
321	≤ 0 .08	≤1.0	≤2.0	≤0.035	≤ 0.03	9.0 - 13 .0	17.0 -1 9.0	-
630	≤ 0 .07	≤1.0	≤1.0	≤0.035	≤ 0.03	3.0-5.0	15.5-17.5	-
631	≤0.09	≤1.0	≤1.0	≤0.030	≤0.035	6.50-7.75	16.0-18.0	-
904L	≤ 2 .0	≤0.045	≤1.0	≤0.035	-	23.0·28.0	19.0-23.0	4.0-5.0
2205	≤0.03	≤1.0	≤2.0	≤0.030	≤0.02	4.5-6.5	22.0-23.0	3.0-3.5
2507	≤0.03	≤0.8	≤1.2	≤0.035	≤0.02	6.0-8.0	24.0-26.0	3.0-5.0
2520	≤0.08	≤1.5	≤2.0	≤0.045	≤ 0.03	0.19 -0. 22	0. 24 -0 . 26	-
410	≤0.15	≤1.0	≤1.0	≤0.035	≤ 0.03	-	11.5-13.5	-
430	≤0.1 2	≤0.75	≤1.0	≤ 0.040	≤ 0.03	≤0.60	16.0 -18.0	-
