ASTM SA213 TP310H SS Boiler Tubes Stainless Steel Seamless Pipe
Product Details
| Material: | TP304H,TP310H,TP316H, TP321H,TP347H,TP347HFG | Finishing: | Solution Annealed & Pickled |
|---|---|---|---|
| Application: | Boiler Tube | Shape: | Round Seamless |
| OD: | 33mm To 273mm | WT: | 2mm To 20mm |
| Highlight |
TP310H Stainless Steel Seamless Pipe,ASTM SA213 Stainless Steel Seamless Pipe,TP310H SS Boiler Tubes |
||
Product Description
ASTM SA213 TP310H Ss Boiler Tubes Stainless Steel Seamless Pipe 0.25"MW
Certification: China National Accreditation Service for Conformity Assessment CNAS certification, with domestic and international standard testing.
Ability: The testing items include routine physical performance testing, chemical analysis testing, metallographic analysis, intergranular corrosion, and high-Low temperature impact test, etc.
Standard Specification:
ASTM A213 / A213M - 11a:Standard Specification for Seamless Ferritic and Austenitic Alloy-Steel Boiler, Superheater, and Heat-Exchanger Tubes
ASTM A269 - 10:Standard Specification for Seamless and Welded Austenitic Stainless Steel Tubing for General Service
ASTM A312 / A312M - 12:Standard Specification for Seamless, Welded, and Heavily Cold Worked Austenitic Stainless Steel Pipes
ASTM A511 / A511M - 12:Standard Specification for Seamless Stainless Steel Mechanical Tubing
ASTM A789 / A789M - 10a:Standard Specification for Seamless and Welded Ferritic/Austenitic Stainless Steel Tubing for General Service
ASTM A790 / A790M - 11:Standard Specification for Seamless and Welded Ferritic/Austenitic Stainless Steel Pipe
DIN 17456-2010:GENERAL PUROSE SEAMLESS CIRCULAR STAINLESS STEEL TUBES.
DIN 17458-2010:Seamless Circular of Austenitic Stainless Steel Tube
EN10216-5 CT 1/2 : Stainless Steel Seamless Pipe & Tube
GOST 9941-81:SEAMLESS COLD- AND WARM-WORKED TUBES MADE OF CORROSION RESISTANT STEEL.
Others like BS, JIS standard or can supply
| Goods | Standard size |
| Stainless steel seamless tube & pipe | OD: φ6-φ813mm, WT: 0.5-40mm |
| U-Tube | OD: φ12-φ38mm, WT: 0.5-4mm |
| Welded tube & pipe | OD: φ17.15-φ1828mm, WT: 0.5-45mm |
| Pipe Fitting | OD: 1/4”~48”, WT: 5S-40S |
| Item No. | Steel types | Typical steel grade |
| 1 | Austenitic |
TP304, TP304L, TP304H, TP316, TP316H, TP316Ti, TP316L, TP321, TP321H, TP347H, TP347HFG, 904L, TP310H, TP310S, TP317, TP317L, TP316LMo≥2.5; etc |
| 2 | Super Austenite | N08904;N08367;S31254 |
| 3 | Duplex/Super duplex | S31803; S32205; S31500; S32750；LC65-2506;LC80-2507 |
| 4 | Ni-Alloy |
UNS NO2200;NO2201;NO4400;N06600;N06601;NO6690;NO6045; N06625; NO6603;N008800;N08810;N08811;N08020;N08825;N08828; |
| 5 |
API Corrosion Resistant Alloy |
LC30-1812; LC65-2205; LC65-2506; LC80-2507; LC30-2242 |
Material Grade:
| American Standard |
Austenitic Steel: TP304,TP304L,TP304H, TP304N, TP310S,TP316,TP316L,TP316Ti,TP316H, TP317,TP317L, TP321, TP321H,TP347, TP347H,904L… Duplex Steel : S32101,S32205,S31803,S32304,S32750, S32760 Others:TP405,TP409, TP410, TP430, TP439,... |
| Europen Standard | 1.4301,1.4307,1.4948,1.4541,1.4878,1.4550,1.4401,1.4404,1.4571,1.4438, 1.4841,1.4845,1.4539,1.4162, 1.4462, 1.4362, 1.4410, 1.4501 |
| Russia Standard | 08Х17Т,08Х13,12Х13,12Х17,15Х25Т,04Х18Н10,08Х20Н14С2, 08Х18Н12Б,10Х17Н13М2Т,10Х23Н18,08Х18Н10,08Х18Н10Т, 08Х18Н12Т,08Х17Н15М3Т,12Х18Н10Т,12Х18Н12Т,12Х18Н9, 17Х18Н9, 08Х22Н6Т, 06ХН28МДТ |
Final Finishing:
Solution Annealed & Pickled
ANSI B16.10: B16.19 SCH 5S, SCH 10S, SCH 20, SCH 30, SCH 40S, SCH 60, SCH80S, XS, SCH 100, SCH 120, SCH160, XXS
Application:
- Food processing equipment, particularly in beer brewing, milk processing & wine making.
- Kitchen benches, sinks, troughs, equipment and appliances
- Architectural panelling, railings & trim
- Chemical containers, including for transport
- Heat Exchangers
- Woven or welded screens for mining, quarrying & water filtration
- Threaded fasteners
- Springs
- Ship building, onshore , offshore, Maire.
